Description
CPU | |
---|---|
CPU Details | 880 MHz Dual-Core |
Memory/Storage | |
Flash/ROM | 16 MB (128 Mbit) NOR |
DDR/RAM | 256 MB (2 Gbit) DDR3 |
Interfaces | |
Gigabit RJ45 Ports | 5 |
Gigabit RJ45 PoE Ports | #2~#5 |
Max Power on a Single PoE Ports | 30W |
PoE Ports Notes | The PoE ports comply with IEEE 802.3at/af standards. |
Ethernet Notes | 1× WAN Port, 4× LAN Ports |
USB-A 3.0 Ports | 1 |
LED |
|
Physical Buttons | Reset Button |
Power Input | DC Jack |
Power | |
Power Methods |
|
DC | 54V 1.11A |
Passive PoE | 24/48V |
Power Adapter | Input: 100 ~ 240 V, 50 Hz AC Output: 54V 1.11A DC |
Max Power Consumption (W) | Total: 60W PoE: 55W PoE (when USB Device is plugged in): 50W No PoE: 5W |
Idle Power Consumption (W) | 2W |
Reliability | |
EMS | IEC/EN 61000-4-2, Level 3 ESD: Contact: 6kV; Air: 8kV |
Environment | Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉) Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉) Operating Humidity: 5% ~ 95% non-condensing Storage Humidity: 0% ~ 100% non-condensing |
