Description
CPU | |
---|---|
CPU Details | 1.3 GHz Dual-Core CPU |
Memory/Storage | |
Flash/ROM | 128 MB (1 Gbit) NAND |
DDR/RAM | 256 MB (2 Gbit) DDR3 |
Wireless | |
5 GHz Wi-Fi Speed | 2402Mbps |
2.4 GHz Wi-Fi Speed | 574 Mbps |
5 GHz Wi-Fi Streams | 2T2R (2×2 MIMO) with an Extra Stream |
2.4 GHz Wi-Fi Streams | 2T2R (2×2 MIMO) |
Wi-Fi Antennas | 3× Internal |
FEM or PA/LNA |
|
Beamforming | True |
Range Performance | Max: 80 m (262 ft) Tested in open-space environments with minimal interference. Actual WiFi range may vary depending on layout and wall materials. Refer to the Wall Performance specifications for placement suggestions. |
Wall Performance | Two wooden walls with thickness < 10 cm (4'') One concrete wall with thickness < 20 cm (7'') |
Interfaces | |
Gigabit RJ45 Ports | 5 |
Ethernet Notes | The port on the back accepts PoE powering. One port on the front bottom supports PoE passthrough |
LED | System |
Physical Buttons |
|
Power Input | PoE via Ethernet Port |
Power | |
Power Methods |
|
Passive PoE Input | 48V |
Max Power Consumption (W) | 12 W (48 V PoE) |
Idle Power Consumption (W) | 5 W (48 V PoE) |
Reliability | |
Advanced | Hardware Watchdog |
EMC | ESD: Contact: 4kV; Air: 8kV |
Environment | Operating Temperature: 0 ℃ ~ 40 ℃ (14 ℉ ~149 ℉) Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉) Operating Humidity: 10% ~ 90% non-condensing Storage Humidity: 5% ~ 90% non-condensing |
