Description
|
Manufacturer
|
UNI-T | |
|
Type of meter
|
digital multimeter | |
|
Measurement
|
AC voltage, capacitance, DC current, DC voltage, duty cycle, frequency, resistance | |
|
Kind of display used
|
LCD | |
|
Display parameters
|
(6000) | |
|
Bargraph
|
yes | |
|
DC voltage measuring range
|
600mV/6V/60V/600V/1kV | |
|
DC voltage measuring accuracy
|
±(0,5% + 3 digits) | |
|
AC voltage measuring range
|
600mV/6V/60V/600V/750V | |
|
AC voltage measuring accuracy
|
±(0,7% + 3 digits) | |
|
DC current measuring range
|
600µA/6000µA/60mA/600mA/6A/20A | |
|
AC current measuring range(1) indirect measurement)
|
600µA/6000µA/60mA/600mA/6A/20A | |
|
DC current measuring accuracy
|
±(0,8% + 3 digits) | |
|
AC current measuring accuracy
|
±(1% + 3 digits) | |
|
True effective value measurement
|
True RMS | |
|
Resistance measuring range
|
600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ | |
|
Resistance measuring accuracy
|
±(0,8% + 2 digits) | |
|
Capacitance measuring range
|
6nF/60nF/600µF/6mF/60mF | |
|
Capacitance measuring accuracy
|
±(3% + 5 digits) | |
|
Frequency measuring range
|
60...10MHz | |
|
Frequency measuring accuracy
|
±(0,1% + 4 digits) | |
|
Duty cycle factor
|
0.1...99.9% | |
|
Test
|
diodes | |
|
Continuity test
|
acoustic indication | |
|
Operating temperature
|
0...40°C | |
|
IP rating
|
IP65 | |
|
Weight with battery
|
473g | |
|
Conform to the norm
|
CAT III 1000V CAT IV 600V EN 61010 | |
|
Resistance to
|
fall from 2m height | |
|
Dimensions (W x H x D)
|
95x195x58mm | |
|
Illumination
|
yes |
