Specifications
|
Rated Power Output
|
2x120W
|
|
Constant Pressure Output
|
100V
|
|
Input Sensitivity And Impedance
|
MIC1/2/3: ±5mV/600Ω (Unbalanced input); AUX: 350mV/10KΩ, (Unbalanced input)
VCD: 350mV/10KΩ, (Unbalanced input); EFFECTOR IN:350mV10KΩ, (Unbalanced input)
|
|
Front Output
|
EFFECTOR OUT: 350mV470Ω; AUDIO OUT: 1V±50mV/470Ω
|
|
Microphone Tone
|
low-frequency: ±10dB at 100Hz,high frequency: ±10dB at 10KHz
|
|
Music Tone
|
low-frequency: ±10dB at 100Hz,high frequency: ±10dB at 10KHz
|
|
Effectors Parameters
|
DELAY: 80ms-240ms; ECHO : 1-12, REPEAT: 0.1s-2s
|
|
Frequency Response
|
AUX,VCD: 20Hz(±3dB) -- 20KHz(±3dB); MIC: 50Hz(±3dB) -- 16kHz(±3dB)
|
|
Noise-signal Ratio
|
Mic :≥65dB, music: ≥70dB
|
|
Harmonic Distortion
|
Distortion of power amplifier on rated output power≤1%
|
|
Indicator Light
|
power light
|
|
Cooling-down Method
|
air-cooled
|
|
Guard Mode
|
Over temperature / short circuit
|
|
Supply Voltage
|
~220-240V 50/60Hz
|
|
Dimension
|
484 x 300 x 44mm
|
|
Fuse Size
|
T3.15A-250V-5x20
|
|
Power Consumption
|
TS-2120WV: 300W |
