Description
| Model number (volume) | HDWG780UZSVA |
| Interface | SATA 6.0 Gbit/s |
| Format | 3.5 inches |
| Advanced Format (AF) | Yes |
| RoHS compliant | Yes |
| Area dimension | 512e |
| Supported bay units | up to 8 |
| Rotary Vibration (RV) Sensors | Yes |
| Native Command Queuing (NCQ) | Yes |
| Shock Sensors | Yes |
| Toshiba Cache Technology | Yes |
| Recording technology | CMR |
| Rotational speed (RPM) | 7200 |
| Maximum Data Transfer Speed | 281 |
| Cache Size [MB] | 512 |
| 24/7 Operation / Hours per Year | Yes/8760 |
| Maximum workload rate | 180 |
| MTTF/MTBF [Hours] | 1,000,000 |
| Unrecoverable error rate | 1 in 10 |
| Charge/discharge cycles | 600,000 |
| Electrical Voltage |
5 VDC + 10% / -7% 12 VDC ±10% |
| Power Consumption (Operational) [W] | 8.19 |
| Power Consumption (Idle Active) [W] | 4.92 |
| Temperature (Operating) [°C] | 5 to 60 (surface) |
| Temperature (Non-Operating) [°C] | -40 to 70 |
| Vibration (Operational) [m/s2] |
7.35 {0.75 G} (5 to 300 Hz) 2.45 {0.25 G} (300 to 500 Hz) |
| Vibration (non-operational) [m/s2] | 29.4 {3.0 G} (5 to 500 Hz) |
| Shock (Operational) [m/s2] | 686 {70 G} (2 ms duration) |
| Shock (Non-Operational) [m/s2] | 2450 {250 G} (2 ms duration) |
| Acoustics (Sound Power) Idle Mode [dB] | 34 |
| Height [mm Max.] | 26.1 |
| Length [mm Max.] | 147.0 |
| Width [mm Max.] | 101.85 |
| Weight [g Max.] | 730 |
