Description
Camera
Image Sensor: 1/2.7" Progressive Scan CMOS
Max. Resolution: 3840 × 2160
Min. Illumination: Color: 0.01 Lux @ (F2.0, AGC ON), B/W: 0 Lux with IR
Shutter Time: 1/3 s to 1/100,000 s
Day & Night: IR cut filter
Angle Adjustment: Pan: 0° to 360°, Tilt: 0° to 90°, Rotate: 0° to 360°
Lens
Lens Type: Fixed focal lens, 2.8 mm and 4 mm optional
Focal Length & FOV:
2.8 mm – Horizontal FOV: 113°, Vertical FOV: 62°, Diagonal FOV: 134°
4 mm – Horizontal FOV: 90°, Vertical FOV: 49°, Diagonal FOV: 108°
Lens Mount: M12
Iris Type: Fixed
Aperture: F2.0
DORI (Detect, Observe, Recognize, Identify)
2.8 mm: D: 79 m, O: 31 m, R: 15 m, I: 7 m
4 mm: D: 102 m, O: 40 m, R: 20 m, I: 10 m
Illuminator
Supplement Light Type: IR, White Light
Supplement Light Range: Up to 30 m
Smart Supplement Light: Yes
IR Wavelength: 850 nm
Video
Main Stream (50 Hz): 12.5 fps (3840×2160, 3200×1800, 2688×1520, 1920×1080, 1280×720)
Main Stream (60 Hz): 15 fps (3840×2160, 3200×1800, 2688×1520, 1920×1080, 1280×720)
Sub-Stream (50 Hz): 12.5 fps (1280×720, 640×480, 640×360)
Sub-Stream (60 Hz): 15 fps (1280×720, 640×480, 640×360)
Video Compression:
Main: H.265+/H.265/H.264+/H.264
Sub: H.265/H.264/MJPEG
Video Bit Rate: 32 Kbps to 16 Mbps
H.264 Type: Baseline Profile, Main Profile, High Profile
H.265 Type: Main Profile
Bit Rate Control: CBR, VBR
Region of Interest (ROI): 1 fixed region for main stream
Scalable Video Coding (SVC): Supported (H.264 and H.265)
Audio
Audio Type: Mono sound
Sampling Rate: 8 kHz / 16 kHz
Environment Noise Filtering: Yes
Audio Compression: G.711, G.722.1, G.726, MP2L2, PCM, AAC-LC
Audio Bit Rate:
G.711 (ulaw/alaw): 64 Kbps
G.722.1: 16 Kbps
G.726: 16 Kbps
MP2L2: 32 to 160 Kbps
AAC-LC: 16 to 64 Kbps
Network
Security:
Password protection, complex password, watermark, HTTP authentication (basic/digest), WSSE, ONVIF authentication, security audit log, MAC host authentication
Simultaneous Live View: Up to 6 channels
API Support: ONVIF (Profile S, T, G), ISAPI, SDK
Supported Protocols:
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP, UPnP
Users/Host Access:
Up to 32 users
User levels: administrator, operator, user
Client Software: iVMS-4200, Hik-Connect
Web Browser Compatibility:
Live view plug-in: IE 10, IE 11
Local service: Chrome 57+, Firefox 52+, Edge 89+
Wide Dynamic Range (WDR): 120 dB
SNR: ≥ 52 dB
Day/Night Switch Modes: Day, Night, Auto, Schedule
Image Enhancement: BLC, HLC, 3D DNR
Image Settings:
Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance (adjustable via client or web)
Privacy Mask: Up to 4 programmable polygon masks
Interface
Ethernet Port: 1 RJ45 10/100 Mbps, self-adaptive
On-Board Storage: Supports microSD/microSDHC/microSDXC (up to 512 GB)
Microphone: Built-in
Speaker: Built-in, max power: 1.5 W, max SPL (10 cm): 95 dB
Reset Button: Yes
Events
Basic Events:
Motion detection (supports human/vehicle classification), video tampering, exceptions
Linkage Actions:
Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, capture, audible warning, flashing light
General
Power Supply:
12 VDC ± 25%, 0.66 A, max. 8 W (coaxial plug Ø5.5 mm, reverse polarity protection)
PoE: IEEE 802.3af, Class 3, max. 9.5 W
Material: Metal and plastic
Camera Dimensions: 179 mm × 67.4 mm × 69.1 mm (7.1" × 2.7" × 2.7")
Package Dimensions: 216 mm × 121 mm × 118 mm (8.5" × 4.8" × 4.6")
Weight (Net / Packaged): Approx. 285 g (0.6 lb) / 490 g (1.1 lb)
Storage Conditions: -30 °C to 60 °C (-22 °F to 140 °F), ≤ 95% RH (non-condensing)
Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F), ≤ 95% RH (non-condensing)
Language Support: English, Ukrainian
General Functions: Heartbeat, anti-banding, mirror, password protection, email-based password reset
Flashing Light: Yes
