Specifications
* Built-in Wire Specifications: Built-in wire length is 30 cm, conductor material: 34 AWG (7/0.06T), core material: tin-plated copper
* Input Port Specifications
1x USB-C: A USB port for connecting to the main device (laptops, smartphones, tablets, etc.). Compliant with USB 3. Standard, theoretical speed up to 5Gbps, compatible with USB 2.0/1.1. Compliant with DP1.4 specifications, with a bandwidth of 8.1 Gbps per Lane and a total of 16.2 Gbps for 2 Lane, it supports up to 4K60Hz video resolution input and is backward compatible with low resolutions. Supports charging laptops, providing up to 85W of charging power. 1x USB-C Female: Screen-printed icon marked as Lightning, used to connect PD power adapters. Compliant with PD3.0 specifications, it supports a maximum power input of 20V/5A and 100W, and is compatible with different voltages such as 15V, 9V, and 5V. A1&A2: Fixed withholding 5W power; A3: The product uses dynamic withholding, with PD power ≤ 45W and 5W; 45W < PD power ≤ 90W and 10W; 90W < PD power ≤ 100W and 15W. PS: Only supports charging and does not support data and video transmission.
* Output Port Specifications
1x HDMI-Out: Type-A connector base for connecting to a TV or display. Compliant with HDMI 2.0 standards, it supports up to 4K60Hz video resolution output and is backward compatible with 4K30Hz, 2K144Hz/120Hz/60Hz, 1080P240Hz, 720P, and 480P. Supports HDCP, supports HDR, does not support CEC/ARC.
2x USB-A: Screen-printed at 5Gbps for connecting USB devices (such as keys, mice, USB drives, hard drives, cameras, speakers, etc.). Compliant with USB 3.0 standards, with a theoretical speed up to 5Gbps and backward compatible with USB 2.0/1.1. 2x USB-C: Screen-printed as 5Gbos, used to connect USB devices (such as keys, mice, USB drives, hard drives, cameras, speakers, etc.). Compliant with USB 3.0 standards, with a theoretical speed up to 5Gbps and backward compatible with USB 2.0/1.1. 1x SD: Supports the SD3.0 protocol with a theoretical speed of up to 104 MB/s, supporting dual-SIM dual-read.
1x TF: Supports SD3.0 protocol with a theoretical speed of up to 104 MB/s, supporting dual-SIM dual-read.
1x RJ45: The 8-pin interface socket does not come with a light and is used to connect to Ethernet. Maximum speed: 1Gbps, backward compatible with 100M/10M, compliant with network technology standards, supporting protocols such as IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, and IEEE802.3x.
* Indicator Light Description: No indicator light
* Button Function: No buttons
* Power requirements: Powered by the main device or connected to a PD power adapter via a USB-C port.
* Product power consumption: No-load power ≈ 186 mA, connected to HDMI ≈ 286 mA
* Video formats: RGB 8/10/12 bpc, YBCBR (444, 422, 420) 8/10/12 bpc
* Audio format：PCM、DTS AUDIO、DTS-HD、Dolby TrueHD、Dolby Digital、Dolby Digital Plus、Dolby Atmos
* Audio sampling rate supports up to 192kHz 24-bit
* Audio output simultaneously： /
* Image Output Mode： A+A (Copy)/A+B (Extension)
* USB limited current 2x USB-A+2x USB-C total limited current 2A
* Variable refresh rate: Does not support VRR, G-sync, or Free-sync
* Dolby Vision/Atmos Supports Dolby Atmos
* EDID processing method (approximate pronunciation/)
Video)
Read the display's EDID
* USB-C extension cable not supported
* Screen delay is virtually non-delayed
* Support for game consoles: Steam Deck, ROG Ally, Lenovo Legion Go, Nintendo Switch
* Operating temperature: 0℃~40℃
* Storage temperature: -20℃ to 60℃
* Measured Temperature: Under room temperature of 25°C (when operating at full load), the product surface temperature is approximately 44.7°C.
* Drive Requirements: Driver-Free Use
* Supported systems: Windows, macOS, Linux
* Upgrade Methods
A1: The FL7102 chip supports online upgrades for Windows computers via the PD interface (using the "FLHubTool_V17.0.18.4" tool to upgrade via USB-C connection).
A2&A3: 1. IT6225BFN uses UpgradeIT6225_2LANE_USB for online upgrades on Windows computers; 2. GL3224 uses MultiTool for online upgrades on Windows computers.
