Specifications
* Self-contained Wire Specifications: Self-contained wire is 20 cm long, conductor material: 34 AWG (7/0.06T), core material: tin-plated copper
* Input Port Specifications
◆1xUSB-C Male: Used for connecting primary devices (computers, tablets, smartphones, etc.), compliant with USB 3.1 Gen2 standards, theoretical transfer rate up to 10Gbps, backward compatible with USB 2.0/1.1; supports 4K60Hz and low resolution; supports HDR; supports PD 3.0 protocol, provides up to 85W charging power via a power connection.
◆1xPD Female: USB-C interface for connecting PD chargers, supporting PD3.0, up to 20V 5A 100W charging, compatible with different voltages including 15V, 9V, and 5V. Using dynamic withholding methods, PD power ≤ 45W < 90W, 10W; 90W < PD power ≤ 100W, 15W.
* Output Port Specifications
◆1xHDMI Female: Type-A interface for connecting displays or TVs, compliant with HDMI 2.0 standards, supports up to 4K60Hz resolution, is backward compatible with low resolutions; does not support CEC/ARC; supports HDR. ◆2xUSB3.0-A Female: Used for connecting USB devices (keyboard, USB flash drive, hard drive, camera), compliant with USB 3.1 GEN2 standards, theoretically capable of transferring up to 10 Gbps, and backward compatible with USB3.0/USB2.0/1.1. ◆2xUSB3.0-C Female: Used for connecting USB devices (keyboard, USB flash drive, hard drive, camera), compliant with USB 3.1 GEN2 standards, theoretically capable of transferring up to 10 Gbps, and backward compatible with USB3.0/USB2.0/1.1. * Indicator Light Description: White indicator light, status see point three of the precautions.
* Button Function: No buttons
* Power supply requirements: powered by the main equipment or connected to a PD power supply.
* Product power consumption: no-load ≈ 1.02W (5V203mA), full-load ≈ 2.45W (5V489mA)
* Video formats: RGB 8/10/12 bpc, YBCBR (444/422/420) 8/10/12 bpc
* Audio format： LPCM、DTS AUDIO、DTS-HD、Dolby TrueHD、Dolby Digital、Dolby Digital Plus、Dolby Atmos
* Audio sampling rate supports up to 192 kHz with 24-bit resolution, compatible with low sampling rates.
* Audio output simultaneously： /
* Image Output Mode： A+A (Copy)/A+B (Extension)
* USB current limit: 2xUSB-A + 2xUSB-C total current limit: 2.5A
* Variable Refresh Rate： /
* Dolby Atmos: Supports Dolby Atmos
* EDID Processing Method (Audio/Video): Read the displayed EDID
* USB-C extension cable not supported
* Screen delay is virtually non-existent.
* Supports gaming consoles including Nintendo Switch, Steam Deck, ROGally, and Lenovo Legion Go
* Operating temperature: 0℃~40℃
* Storage temperature: -10℃ to 60℃
* Measured Temperature: At room temperature of 25°C, the maximum surface temperature of the housing during full-load operation is 36.2°C.
* Driver Requirements: Driver-Free Use
* Supported systems: Compatible with Windows/MAC OS/LINUX/IOS systems
* Upgrade Method: The HDMI chip only supports online upgrades under the WINDOWS system (use the "Bulldog Aux_Update tool" tool to upgrade via USB-C connectivity).
