Specifications
* Input:100-240V~50/60Hz 900mA Max
* USB Output:
Single-port output:
C:5V/3A 9V/3A 12V/2.9A 15V/2.33A 20V/1.75A 35W Max PPS: 5-11V/3A
A: 5V/3A 9V/2A 12V/1.5A 10V/2.25A 22.5W Max
Dual-port output:
C : 5V/2.0A、9V/2.77A、12V/2.08A 25WMax PPS: 5-11V/2.75A
A : 5V/1.5A 7.5W Max
* Total Output Power: 35W Max
* No-load power consumption: ≤0.3W
* Support Protocals:
USB-C:PD3.0、PPS、QC4.0、QC3.0、QC2.0、FCP、AFC、APPLE 5V2.4A、Sumsung 5V2A、BC1.2
USB-A:SCP、QC3.0、QC2.0、FCP、AFC、APPLE 5V2.4A、Sumsung 5V2A、BC1.2
* Protection Types:Output Overcurrent/Overvoltage/Overtemperature/Short Circuit Protection
* Output ripple: 5V ≤: 180mV, 9V ≤ 200mV, 12V ≤ 200mV, 15V ≤ 200mV, 20V ≤ 200mV
* Shell temperature: 77°C (environmental temperature: 25°C, safety standard temperature rise)
* Operating temperature: -10°C to 25°C (safety test ambient temperature)
* Storage temperature: -20°C to 80°C
* Shell Material/Fire Resistance Rating:PC Material/UL94-V0
* Application altitude ≤ 2000 meters
