Specifications
* Input 100~240V AC, 50/60 Hz, maximum 1.8 amperes
* USB output USB-C cable: 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/5A, 100W Max PPS: 5-21V/5A (PDO broadcast)
USB-C1：5V/3A 、9V/3A 、12V/3A 、 15V/3A 、20V/5A 100W Max PPS：5-21V/5A （PDO）
USB-C2：5V/3A 、9V/3A 、12V/2.5A 、15V/2A 、20V/1.5A 30W Max PPS：5-11V/2.75A （PDO）
USB-A： 5V/3A 、9V/2A 、12V/1.5A 、 10V/2.25A 22.5W Max
Multiple outputs can be seen in the power distribution table.
* Output total power: 100W Max
* Static power consumption ≤ 0.3 million
* Output voltage range ±5% of the rated voltage
* Output ripple: 5V ≤ 150mV, 9V ≤ 150mV, 12V ≤ 180mV, 15V ≤ 180mV, 20V ≤ 200mV
* Support protocol：USB-C Cable：UFCS(63W)、PD3.0/2.0、PPS、QC3.0（3.6V~12V）、QC2.0（5V/9V/12V）、AFC（9V/12V-max 18W）、SCP(10V/2.25A）、FCP（9V/12V-max 18W）、APPLE 2.4A、SAMSUNG 5V/2A、BC1.2 （5V/1.5）
USB-C：PD3.0/2.0、PPS、QC3.0（3.6V~12V）、QC2.0（5V/9V/12V）、SCP(10V/2. ）、
FCP（9V/12V-max 18W）、APPLE 2.4A、SAMSUNG 5V/2A、BC1.2 （5V/1.5）
USB-A: QC3.0（3.6V~12V）、QC2.0（5V/9V/12V）、SCP(10V/2.25A）、FCP（9V/12V-max 18W）、APPLE 2.4A、SAMSUNG 5V/2A、BC1.2 （5V/1.5）
* Protection Types: Overvoltage/Short Circuit/Overcurrent Protection
* Conversion efficiency meets Level 6 energy efficiency standards
* Output Overtemperature Protection Value: After the NTC detection temperature reaches the set value, output power reduction
* Output overvoltage protection value 110%-130% of the rated output voltage
* Output overcurrent protection value: 105%-130% of the rated output current
* Filtering function available
* Shell temperature: ≤77℃ (environmental temperature 25℃, full load test)
* Operating temperature: -10~25℃ (safety standard test working environment temperature)
* Storage temperature: -20°C to 80°C
* Application altitude ≤ 5000 meters
* Shell material/fire rating: PC / Fire-resistant V0 fire rating
* Number of interface pins: USB-C:16 PIN, USB-A:4 password
* Extension line length: 0.75 meters
* Other retractable lines need to be pulled forward and then released to automatically recover.
