Specifications
Features:
Aqara Smart Wall Switch H1 EU WS-EUK01 (No Neutral) is based on the Zigbee 3.0 wireless communication protocol. It can control the on/off status of lights. With the Aqara Hub, it can realize functions such as app remote control and timing control. It can work with other Aqara smart devices to realize more smart scenes.
Automate Traditional Lights with Ease
Aqara Smart Wall Switch H1 EU (No Neutral, Single Rocker) (WS-EUK01) can turn traditional lights into smart devices easily. Numerous smart scenes can be realized when it works with other Aqara smart devices.
Remote Control with Your Phone
Forgot to turn off the fan when you hurry outside? Just take out your phone and open Aqara Home app. Then, you can turn off all the lights at your home easily.
Timed Switching Provides You with a Disciplined Life
19:00 Lights automatically turns on before you arrive home to provide you with a comfortable environment.
Control Lights with Your Voice Easily
You can use your favorite voice assistant to enjoy a smart life.
Connected Automation, Stable and Smart
When the network at your home is not stable or disconnected, as long as the Hub is working normally, the connected automation between Smart Wall Switch H1 EU (No Neutral, Single Rocker) (WS-EUK01) and sensors can still work properly.
Overheat and Overload Protection
When Smart Wall Switch H1 EU (No Neutral, Single Rocker) (WS-EUK01) detects that the power or temperature is over the limit threshold, it will automatically cut off the power to protect you from any danger.
!!! This device is EU version, and is intended to use with EU version of Aqara Hub EU. !!!
FEATURES :
- Remote control of load to 8A (resistive load)
- Minimum power is 3W
- Zigbee 3.0
- Fits into 45 mm depth junction box
- No need for a Neutral cable
- Overheat & Overload Protection
Specification:
Model: WS-EUK01
Dimensions: 85.8×86×37.55mm
Wireless Protocol: Zigbee 3.0
Electrical Rating: 100-250VAC, 50/60Hz, Max. 8A (resistive load)
Minimum Power: 3W (typical)
Operating Temperature: 0°C to 40°C
Operating Humidity: 0%~95% RH, Non-condensing
Zigbee Operation Frequency: 2405-2480MHz
Zigbee Maximum Output Power 13dBm
What's in the Box:
Smart Wall Switch x 1
Quick Start Guide x 1
Screw x 2
