Specifications
- Product Model
- Product ModelDS-D5C65RB/B2L
- Display
- Screen Size65 inch
- BacklightDLED
- Pixel Pitch0.124 (H) × 0.372 (V) mm
- Resolution3840 × 2160 @60 Hz
- Brightness480 cd/m² (Typ.)
- Color Depth10 bit (8 bit + FRC)
- Display Color1.07 G
- Response Time5 ms
- Panel TypeVA
- Contrast Ratio
5000:1 (Static)
30,000:1 (Dynamic) - Color Gamut72% NTSC (CIE1931) (Typ.)
- Refresh Rate60 Hz
- Viewing Angle178° (H)/178° (V)
- Aspect Ratio16:9
- Surface Hardness
9H (Pencil)
7 (Mohs) - Surface GlassAnti-Glare Glass
- Surface Haze25% Haze
- Glass Bonding MethodZero Lamination
- Display Area1428.48 (H) × 803.52 (V)
- Working Duration7 × 16 H
- Transmittance88% ± 3
- Lifespan50,000 hours
- Touch
- TypeInfrared Touch Screen
- Touch PointUp to 50-point multi-touch
- Touch Response Time≤ 2 ms
- Minimum Touch Object≥ 1.5 mm (≥ 90% touching area)
- Touch Precision± 0.5 mm (≥ 90% touching area)
- Touch Resolution32768 × 32768
- Built-in System
- Operation SystemAndroid 14.0
- Memory8 GB
- Built-in Storage128 GB
- ProcessorQuad-core Cortex-A76 × 4（2.4 GHz）and quad-core Cortex-A55 × 4（1.8 GHz）
- GPUMali-G610 MC4
- HDCP Version2.3 & 2.0 & 1.4
- Camera
- PixelPixel 48 MP for Photos & 8 MP for Video
- Camera FunctionSupport intelligent switching between Android system, OPS, and PC.
- Field Angle93.4° (diagonal), 84.5° (horizontal), 54.1° (vertical)
- Distortion≤ 2.5%
- Camera Resolution RatioUp to 4K
- Microphone
- SpecificationOmni-directional 8-array layout
- Mic FunctionEcho reduction and smart noise-cancellation
- Voice Distance12 m
- Sampling Rate32 K
- Mic Depth16 bit
- Internal Function
- LoudspeakerBuilt-in 2 × 20 W + 25 W loudspeaker;
- BluetoothBuilt-in BLE (Bluetooth Low Energy) module supports Bluetooth 5.4
- NFC
Support card reader
13.56 MHz, (ISO 14443A/ ISO 14443B/ ISO 15693) - Light SensorYes
- Image Processing TechnologySupport 3D digital noise reduction, face detection, automatic white balance, automatic purple edge removal, automatic defogging; support shadow correction.
- Audio Processing TechnologySupport dereverberation, adaptive noise reduction, adaptive non-stationary noise reduction, adaptive echo cancellation, automatic gain control, automatic electrical level control, sound source localization, speech dynamic detection, digital beam forming, speech detection.
- Humidity and Temperature SensorRelative humidity accuracy: up to ± 1.5 %RH; Temperature accuracy: up to ± 0.1 °C
- Interface
- Video & Audio Input
HDMI 2.1 TMDS × 3（Front x 1; Rear x 2; Support HDCP2.3 & 2.0 & 1.4; Support HDMI CEC protocol）
VGA × 1（Rear）
Audio × 1（Rear） - Video & audio output
HDMI 2.1 TMDS × 1（Rear）
Audio × 1（Rear）
SPDIF × 1（Rear） - Control interface
TOUCH-USB 3.0 × 1（Front × 1）
TOUCH-USB 2.0 × 2（Rear × 2）
RS232 × 1（Rear） - Network Interface
LAN (1000 Mbps) × 2（Rear）
Wi-Fi AP & Station, 2.4 G/5 G
Wi-Fi 6, IEEE 802.11 a/b/g/n/ac/ax 2 × 2 MIMO (2.4 GHz and 5 GHz) authentication protocols WEP, WPA, WPA2, PSK and 802.1X EAP - Data Transmission Interface
USB 3.0 × 4（Front × 2; Rear × 2）
USB 2.0 × 1（Rear）
Type-C × 2 (Front × 1; Rear × 1; Support USB 2.0, 100 W charging functions, DP IN 1.2 ) - Power
- Power Supply100 to 240 VAC, 50/60 Hz
- Standby Consumption≤ 0.5 W
- Average Consumption< 184 W
- Working Environment
- Working Temperature0 °C to 40 °C (32 °F to 104 °F)
- Working Humidity10%~90% RH
- General
- VESA600 mm × 400 mm (4 × M8-25 mm)
- AccessoryWall mount bracket, hook, user manual, touch writing pen, packing list, 3 M touch USB cable, 3.5 M HDMI cable (2.0), 3 M power cable, remote control, screen cleaning cloth.
- Package Dimensions (W × H × D)1662 × 1062 × 223 mm
- Net Weight34.7 ± 0.5 kg
- Gross Weight47.1 ± 0.5 kg
- Product Dimensions （With Wall Attachment）1491.9 × 910.6 × 115.3 mm
- Product Dimensions （Without Wall Attachment）1491.9 × 910.6 × 82.3 mm
