Specifications
| Video I/O | Input 1x BNC (3G-SDI) Output 1x BNC (3G-SDI) (Loop Output) 1x HDMI 2.0 Show Less |
| Video Resolution | BNC Input (8/10-Bit 4:2:2 RGB, YUV) 2048 x 1080 at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 2048 x 1080PsF at 25/29.97/30 fps 1920 x 1080p at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 1920 x 1080PsF at 25/29.97/30 fps 1920 x 1080i at 50/59.94/60 fps 1280 x 720 at 50/59.94/60 fps 768 x 576i at 50 fps 720 x 480i at 59.94 fps SDI Output 2048 x 1080 at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 2048 x 1080PsF at 25/29.97/30 fps 1920 x 1080p at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 1920 x 1080PsF at 25/29.97/30 fps 1920 x 1080i at 50/59.94/60 fps 1280 x 720 at 50/59.94/60 fps 768 x 576i at 25 fps 720 x 480i at 29.97 fps HDMI Output (4:2:2 YUV) 1920 x 1080p at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 1920 x 1080i at 50/59.94/60 fps 1280 x 720 at 50/59.94/60 fps 768 x 576i at 25 fps 720 x 480i at 29.97 fps Show Less |
| Broadcast System Compatibility | NTSC, PAL |
| Wireless | No |
| OS Compatibility | macOS 10.14.15 or Later Windows 10 |
