Specifications
Overview
| Item | Details |
|---|---|
| Interface | PCIe Gen 4.0 x4, NVMe 2.0 |
| Sequential Read | Up to 7,450 MB/s Performance may vary based on system hardware & configuration |
| Sequential Write | Up to 6,900 MB/s Performance may vary based on system hardware & configuration |
| Warranty | 5-year Limited Warranty or 2400 TBW Limited Warranty |
| Application | Client PCs, Game Consoles |
| Weight | Max 9.0 g |
| Dimension (W × H × D) | 80 × 22 × 2.3 mm |
General Features
| Item | Details |
|---|---|
| Application | Client PCs, Game Consoles |
| Capacity | 4,000GB (1GB = 1 Billion byte by IDEMA) Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise) |
| Form Factor | M.2 (2280) |
| Interface | PCIe Gen 4.0 x4, NVMe 2.0 |
| Dimension (W × H × D) | 80 × 22 × 2.3 mm |
| Weight | Max 9.0 g |
| Storage Memory | Samsung V-NAND TLC |
| Controller | Samsung in-house Controller |
| Cache Memory | Samsung 4GB Low Power DDR4 SDRAM |
Special Features
| Feature | Details |
|---|---|
| TRIM Support | Supported |
| S.M.A.R.T Support | Supported |
| Garbage Collection (GC) | Auto Garbage Collection Algorithm |
| Encryption Support | AES 256-bit Encryption (Class 0) TCG/Opal, IEEE1667 (Encrypted drive) |
| WWN Support | Not supported |
| Device Sleep Mode Support | Yes |
Performance
| Performance Metric | Details |
|---|---|
| Sequential Read | Up to 7,450 MB/s |
| Sequential Write | Up to 6,900 MB/s |
| Random Read (4 KB, QD32) | Up to 1,600,000 IOPS |
| Random Write (4 KB, QD32) | Up to 1,550,000 IOPS |
| Random Read (4 KB, QD1) | Up to 22,000 IOPS |
| Random Write (4 KB, QD1) | Up to 80,000 IOPS |
Performance may vary based on system hardware & configuration.
Environment
| Item | Details |
|---|---|
| Average Power Consumption (System Level) | Average: 6.5 W Maximum: 8.6 W (Burst mode) |
| Power Consumption (Idle) | Max. 55 mW |
| Allowable Voltage | 3.3 V ± 5% |
| Reliability (MTBF) | 1.5 Million Hours |
| Operating Temperature | 0 – 70 ℃ |
| Shock | 1,500 G & 0.5 ms (Half sine) |
Actual power consumption may vary depending on system hardware & configuration.
Accessories
| Item | Details |
|---|---|
| Installation Kit | Not Available |
Software
| Item | Details |
|---|---|
| Management Software | Magician Software for SSD management |
