Specifications
| Brand | HIKVISION |
| Range | Value |
| Video format | HDTVI / HDCVI / AHD / CVBS / IP |
| Video inputs | 4 Channels BNC, (HDTVI / HDCVI / AHD / CVBS) |
| Hybrid configuration | 2 Additional IP CH: Up to 6 IP channels (8Mpx), substituting all BNC channels Enhanced IP Mode: 4CH additional IPs: Up to 8 IP Channels (4Mpx), replacing all the BNC channels |
| Available bandwidth | 96 Mbps |
| Video outputs | 1 HDMI 2K and 1 VGA, simultaneous; |
| Display resolution | HDMI: 2560x1440, 1920x1080, 1280x1024, 1280x720 / 60Hz VGA: 1920x1080, 1280x1024, 1280x720 / 60Hz |
| Audio inputs | 1 Channel RCA |
| Audio outputs | 1 Channel RCA |
| Bidirectional audio | Reusing the audio input |
| Audio Bit Rate | 64 Kbps |
| Audio compression | G.711u |
| Video compression | Analog: H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264 IP: H.265+ / H.265 / H.264+ / H.264 |
| Input resolution | HDTVI: 8Mpx (12~15 fps), 3K (20 fps), 5Mpx (12~20 fps), 4Mpx (25~30 fps), 3Mpx (18 fps), 1080p (25~30 fps), 720p (25~60 fps) HDCVI: 8Mpx (12~15 fps), 5Mpx (12~20 fps), 4Mpx (25~30 fps), 3Mpx (18 fps), 1080p (25~30 fps), 720p (25~60 fps) AHD: 5Mpx (12~20 fps), 4Mpx (25~30 fps), 1080p (25~30 fps), 720p (25~30 fps) CVBS: PAL/NTSC |
| Main Stream coding | 8Mpx
(8 fps), 3K (12 fps), 5Mpx (12 fps), 4Mpx (15 fps), 8 MPx Lite (15
fps), 3Mpx (18 fps), 1080p /720p/WD1/4CIF/VGA/CIF (25 fps (P), 30 fps
(N)) * 8Mpx@8 fps is only available for the 1 channel * 8MPx Lite is only available for 2 to 4 channels |
| Extra Stream coding | WD1/4CIF/CIF (25 fps (P), 30 fps (N)) |
| Video Bit Rate | 32 Kbps at 10 Mbps |
| Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Alarms | Does not have |
| Artificial intelligence | Motion detection 2.0: Deep-learning based motion detection, can classify humans and vehicles upon motion detection. Enabled by default on all analog channels * Motion detection and AcuSense cannot be enabled at the same time on the same device. |
| Intelligent functions | AcuSense: VCA rule-based perimeter protection with false alarm filter for human and vehicle detection. Available in up to 4 analog video channels * Motion detection and AcuSense cannot be enabled at the same time on the same device. |
| Face Detection | Yes |
| Recording method | Manual, programmed, motion detection |
| Backup | USB (Memory, HDD, CD-RW, DVR-RW) / Network |
| Internal memory | 1 SATA HDD 3.5" of up to 10 TB (not included) |
| Communication | 2 x USB (Mouse and backup) / RJ45 (Ethernet) |
| Remote connections | 32 |
| Remote access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200 and Hik-Central |
| Power | DC 12 V, 1.5 A, ≤ 15 W (no HDD) |
| Operating temperature | -10° ~ +55° C |
| Dimensions / Weight | 45 mm (H) x 200 mm (W) x 200 mm (D) / ≤ 1.16 Kg (w/o HDD) |
| Colour | White |
