Specifications
Key Specifications:
- Operating Voltage: 12V DC
- Channels: 8
- Trigger Current: 5mA
- Trigger Mode: High/Low Level Trigger (set by jumper)
- Load Capacity (Normally Open): AC 250V/10A, DC 30V/10A
- Dimensions: Approx. 138mm x 56mm x 18.5mm to 141.5mm x 50mm x 18.5mm (slight variations reported)
- Indicator: Power indicator (green), 8 channel status LEDs (red)
- Material: PVC/PCB
Features:
- Optocoupler Isolation: Provides robust, interference-resistant operation.
- Fault-Tolerant Design: The relay will not operate even if the control line breaks.
- Interface: User-friendly terminals for direct wiring.
- Applications: Suitable for SCM development, home appliance control, and industrial automation.
