Key Features and OEM Specifications:
- Distance Measuring Range: 4 cm to 30 cm (approx. 1.5" to 12").
- Output Type: Analog voltage (voltage corresponds to the detection distance, where closer objects produce higher voltage).
- Operating Voltage: 4.5 V to 5.5 V DC.
- Average Current Consumption: 12 mA (typically with high-current, short-burst draws).
- Update Period: 16.5 ± 4 ms.
- Detection Method: Infrared LED + Position Sensitive Detector (PSD).
- Connector Type: 3-pin JST PH connector.
- Operating Temperature: -10°C to +60°C.
- Size: 44.5 mm × 18.9 mm × 13.5 mm (1.75" × 0.75" × 0.53").
Usage Notes:
- Power Supply Stability: It is highly recommended to place a 10 µF or larger capacitor across Vcc and GND close to the sensor to handle current surges.
- Output Voltage: The output varies, generally providing a 2.05V to 2.3V differential over the full distance range.
- Applications: Suitable for cleaning robots, personal robots, and sanitary applications, according to manufacturer specs.
