Specifications
Specifications:
- Input Voltage Range: 18-35V DC
- Output Voltage: 12.5V DC (Nominal)
- Continuous Output Current: 10A (120W)
- Maximum Output Current: 12A (Short-time)
- Efficiency: 97%
- Galvanic Isolation: No (Non-Isolated)
- Off-Load Current: < 45mA
- Operating Temperature Range: -20 to +55°C (with 3% derating per °C above 40°C)
- DC Connection: Screw terminals (max 6mm² / AWG10)
- Protection: IP43 (when installed with terminals facing downwards)
- Dimensions: 73 x 94 x 37 mm
- Weight: 0.2 kg
