Specifications
System Capacity
| Feature | Capacity |
| Wireless Zones | Up to 32 |
| User Accounts | 12 (1 Admin, 10 Users, 1 Installer) |
| Areas/Partitions | 8 |
| Keyfobs | 16 |
| Wireless Sounders | 4 |
| Keypads & Readers | 4 |
| Event Log | 1,000 Events |
Communication & Networking
- RF Frequency: 433.1 MHz ~ 433.7 MHz
- Transmission Range: 1,200m (Open Space)
- Wireless Protocol: 2-Way Wireless (2GFSK)
- Encryption: AES-128
- Network Interfaces: * Ethernet (RJ45 10M)
- Wi-Fi (802.11 b/g/n)
- Cellular (GPRS via Single SIM slot)
Electrical Characteristics
- Power Supply: 110V to 240V AC (Built-in)
- Power Consumption: Max 0.2A
- Battery Type: Built-in Lithium rechargeable battery
- Battery Life: Up to 12 hours (standby)
Physical & Environmental
- Operating Temperature: -10°C to +55°C
- Operating Humidity: 10% to 90% (Non-condensing)
- Dimensions: 155 × 155 × 37.5 mm
- Weight: 407g
- Material: High-quality ABS Plastic
Software & Compatibility
- App Support: Hik-Connect / Hik-ProConnect
- Monitoring Protocols: SIA-DCS, ADM-CID (Contact ID)
- Firmware Updates: OTA (Over-the-Air) supported
- Configuration: Web Portal, App, or IVMS-4200
