Description
Specifications
| Specification | Details |
|---|
| Screen Size | 23.8 inch |
| Active Display Area | 527.04 (H) mm × 296.46 (V) mm |
| Resolution | 1920 × 1080 |
| Backlight | E-LED |
| Pixel Pitch | 0.2745 mm (H) × 0.2745 mm (V) |
| Brightness | 250 cd/m² |
| Viewing Angle | 178° (H) / 178° (V) |
| Color Depth | 16.78 M |
| Contrast Ratio | 1000:1 |
| Response Time | 14 ms |
| Refresh Rate | Typ. 60 Hz, Max. 100 Hz |
| Haze | 25%, 3H |
| Reliability | 7 × 24 H |
| Color Gamut | 72% NTSC |
| Video & Audio Input | HDMI 1.4 × 1, VGA × 1 |
| Video & Audio Output | Audio Out × 1 |
| Data Transmission Interface | None |
| Control Interface | None |
| Power Supply | DC 12V, 2.0A |
| Power Consumption | ≤ 24 W |
| Standby Consumption | ≤ 0.5 W |
| Working Temperature | 0 ℃ to 40 ℃ (32 ℉ to 104 ℉) |
| Working Humidity | 20% to 90% RH (Non-Condensing) |
| Storage Temperature | -20 ℃ to 60 ℃ (-4 ℉ to 140 ℉) |
| Storage Humidity | 10% to 90% RH (Non-Condensing) |
| Casing Material | Plastic |
| VESA | 75 mm × 75 mm (4 - M4 × 6 mm) |
| Bezel Width | 2.0 mm (top/left/right), 23.55 mm (bottom) |
| Product Dimensions (W × H × D) | With base: 539.7 × 427.33 × 185.69 mm (21.25 × 16.82 × 7.31 inch) Without base: 539.7 × 327.33 × 43.5 mm (21.25 × 12.89 × 1.71 inch) |
| Package Dimensions (W × H × D) | 611 × 405 × 118 mm (24.06 × 15.94 × 4.65 inch) |
| Net Weight | 2.85 ± 0.5 kg |
| Gross Weight | 3.85 ± 0.5 kg |
| Packing List | Monitor × 1, Base component × 1, Power adapter (12 V, 2 A) × 1, HDMI cable (1.5 m) × 1, User manual × 1, Multilingual manual × 1 |
