Description
Specifications
| Specification | Details |
|---|
| Screen Size | 21.45 inch |
| Active Display Area | 478.656 (H) mm × 260.280 (V) mm |
| Resolution | 1920 × 1080 |
| Backlight | E-LED |
| Pixel Pitch | 0.241 mm (H) × 0.241 mm (V) |
| Brightness | 250 cd/m² |
| Viewing Angle | 178° (H) / 178° (V) |
| Color Depth | 8 bit, 16.7 M |
| Contrast Ratio | 1000:1 |
| Response Time | 6.5 ms |
| Refresh Rate | Max. 100 Hz, Typ. 60 Hz |
| Haze | 25%, 3H |
| Reliability | 7 × 16 H |
| Color Gamut | 72% NTSC |
| Video & Audio Input | HDMI 1.4 × 1, VGA × 1 |
| Video & Audio Output | Audio Out |
| Data Transmission Interface | None |
| Control Interface | None |
| Power Supply | DC 12V, 2.0A |
| Power Consumption | ≤ 24 W |
| Standby Consumption | ≤ 0.5 W |
| Working Temperature | 0 ℃ to 40 ℃ (32 ℉ to 104 ℉) |
| Working Humidity | 20% to 90% RH (Non-Condensing) |
| Storage Temperature | -20 ℃ to 60 ℃ (-4 ℉ to 140 ℉) |
| Storage Humidity | 10% to 90% RH (Non-Condensing) |
| Casing Material | Plastic |
| VESA | 75 mm × 75 mm (4 - M4 × 6 mm) |
| Bezel Width | 2.38 mm (top/left/right), 21.55 mm (bottom) |
| Product Dimensions (W × H × D) | With base: 493.26 × 393.45 × 185.74 mm Without base: 493.26 × 290.13 × 42.35 mm |
| Package Dimensions (W × H × D) | 599 × 393 × 109 mm |
| Net Weight | 2.0 ± 0.5 kg |
| Gross Weight | 3.2 ± 0.5 kg |
| Packing List | Monitor × 1, Base component × 1, Power adapter (12 V, 2.0 A) × 1, HDMI cable (1.5 m) × 1, User manual × 1, Multilingual manual × 1 |
