Description
Specifications
| Specification | Details |
|---|
| Image Sensor | 1/2.8" 2 MP CMOS |
| Max. Resolution | 1920 × 1080 |
| USB Output | MJPG: 1920 × 1080, 1280 × 960, 1280 × 720 @60/50/30/25 fps H.264: 1920 × 1080, 1280 × 960, 1280 × 720, 640 × 480, 640 × 360 @60/50/30/25 fps YUY2/NV12: 1920 × 1080 @5 fps; 1280 × 960 @10 fps; 1280 × 720 @15 fps; 640 × 480, 640 × 360 @30/25 fps |
| Shutter Time | PAL: 1/25 s to 1/10,000 s; NTSC: 1/30 s to 1/10,000 s |
| Object Distance Range | Wide: 0.1 m to ∞; Tele: 1.5 m to ∞ |
| Optical Zoom | ×12 |
| Digital Zoom | ×4 (YUV Format: ×1.5) |
| Angle Adjustment | Pan: -165° to 165°, Tilt: -30° to 30° |
| Lens | Varifocal lens: 3.4 mm to 40.8 mm, equivalent focal length: 23.1 mm to 277.2 mm |
| FOV | Horizontal: 80.5° to 7.6°, Vertical: 50.5° to 4.4°, Diagonal: 88.9° to 8.7° |
| Focus | Auto/Semi-auto mode, supporting selection of focus area |
| Microphone Type | MEMS, dual-microphone, 360° omni-directional |
| Microphone Pickup Distance | Up to 5 m |
| Microphone Frequency Response | 100 Hz to 8 kHz |
| Sensitivity | -32 ± 3 dBV/Pa |
| SNR | 70 dB(A) |
| Sampling Rate | 16 kHz / 32 kHz / 48 kHz |
| Image Function | Support adjustment of exposure, white balance, DNR, contrast, sharpness, saturation, hue, Gamma, etc. |
| Audio Function | Steady and transient smart noise reduction, automatic gain control, echo suppression, time domain equalization, ambient noise suppression, enhanced vocals |
| Smart Function | Human body following and face focus |
| LED Indicator | Startup: solid white → flashing white → solid white; Working: solid white; Mute: solid red; Shutdown: light off |
| Communication Method | Camera and remote control: 2.4G wireless |
| Wireless Communication Distance | 10 m |
| Wide Dynamic Range (WDR) | ≥120 dB |
| USB Interface | 1 × USB Type-C (supports USB 2.0) |
| Audio Interface | 1 × Line-in (3.5 mm TRS), 1 × Line-out (3.5 mm TRS) |
| Power Interface | 12 VDC, Ø2.1 mm |
| System Compatibility | Windows 7/8/10/11, Android 8.1+, Linux 4.14+, macOS 10.12+ |
| Power | 12 VDC ± 25%, max. 15.9 W |
| Operating Condition | -10 °C to 45 °C (14 °F to 113 °F), Humidity ≤ 90% (non-condensing) |
| Dimension | 148.9 mm × 145.7 mm × 152.1 mm (5.86" × 5.74" × 5.99") |
| Package Dimension | 308 mm × 216 mm × 187 mm (12.13" × 8.5" × 7.36") |
| Net Weight | Approx. 1185 g (2.61 lb) |
| With Package Weight | Approx. 2705 g (5.96 lb) |
| Packing List | Camera (with lens cover) ×1, Remote Control ×1, Power Adapter ×1, Power Adapter Extension Cable ×1, USB 2.0 Cable ×1, Bracket ×1, Screws ×1 |
