Description
Specifications
| Brand | Hikvision |
| Image sensor | 1/2.7" Progressive Scan CMOS |
| Resolution | 4 Mpx (2560x1440) |
| Main Stream rate | 25 fps (2560x1440, 1920x1080, 1280x720) |
| Extra Stream rate | 25 fps (768x432) |
| Compression | H.265, H.264, MJPEG |
| Bitrate | 32 Kbps at 8 Mbps |
| Lens | 2.8 mm fixed lens |
| Viewing angle | H: 94°, V: 49°, D: 114° |
| Minimum illumination | Colour: 0.005 Lux @ (F1.6, AGC ON) B/W: 0 Lux with IR (range 30 m) |
| Day/Night | Removable mechanical ICR filter |
| Motion Detection | Motion detection 2.0 with human and vehicle classification applied in motion detection. |
| Image improvements | DWDR, 3D-NR, BLC, HLC, Mirror effect, Privacy masking |
| Audio | Built-in microphone and speaker |
| Audio Compression | G.711ulaw/AAC-LC |
| Audio bitrate | 64 Kbps (G.711ulaw)/16 a 64 Kbps (AAC-LC) |
| Environmental noise reduction | Yes |
| Network interface | Ethernet 10/100 BaseT Wifi IEEE 802.11b/g/n/ax |
| Internal memory | MicroSD card slot up to 512 GB |
| Power | DC 12 V / 0.5 A / 6 W max. |
| Temp. operation | -30º C ~ +60º C |
| Degree of protection | Weatherproof IP66 |
| Dimensions | 67.4 mm (H) x 113.9 mm (W) x 260.9 mm (D) |
| Weight | 305 g |
NVR | |
| Brand | Hikvision |
| Inputs for IP cameras | LAN port up to 4 channels Wifi IEEE 802.11b/g/n/ax |
| Wi-Fi frequency | 2.4 GHz |
| Wi-Fi transmission speed | 150 Mbps |
| Video compression format | H.265, H.264, MJPEG |
| Total bandwidth | 20 Mbps downstream / 20 Mbps upstream |
| Main Stream recording | 6 Mpx /5 Mpx / 4 Mpx / 3 Mpx / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF |
| Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Recording method | Manual, programmed, motion detection |
| Internal memory | 1 HDD SATA |
| Remote access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200 and Hik-Central |
| Temp. operation | -10º C ~ +55º C |
| Power | DC 12V / 6W |
| Dimensions | 26 (H) x 163 (W) x 125 (D) mm |
| Weight | 500 g (without hard disk) |
