| Camera |
Image Sensor |
1/2.4" Progressive Scan CMOS |
| Max. Resolution |
3200 × 1800 |
| Min. Illumination |
Color: 0.005 Lux @ (F1.6, AGC ON),0 Lux with light |
| Shutter Time |
1/3 s to 1/100,000 s |
| Day & Night |
IR cut filter |
| Angle Adjustment |
Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360° |
| Lens |
lens type |
Fixed focal lens, 2.8, 4, and 6 mm optional |
| focal length & fov |
2.8 mm, horizontal FOV 105°, vertical FOV 55°, diagonal FOV 127° 4
mm, horizontal FOV 78°, vertical FOV 38°, diagonal FOV 96° 6 mm,
horizontal FOV 51°, vertical FOV 26°, diagonal FOV 59° |
| lens mount |
M12 |
| iris type |
Fixed |
| aperture |
F1.6 |
| depth of field |
2.8 mm: 1.8 m to ∞ 4 mm: 3.1 m to ∞ 6 mm: 6.4 m to ∞ |
| DORI |
DORI |
2.8 mm, D: 76 m, O: 30 m, R: 15 m, I: 7 m 4 mm, D: 115 m, O: 45 m, R: 23 m, I: 11 m 6 mm, D: 164 m, O: 65 m, R: 32 m, I: 16 m |
| Illuminator |
Supplement Light Type |
IR,White Light |
| Supplement Light Range |
Up to 40 m |
| Smart Supplement Light |
Yes |
| IR Wavelength |
850 nm |
| Video |
Main Stream |
50 Hz: 25 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) 60
Hz: 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) |
| Sub-Stream |
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) |
| Third Stream |
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz:
10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) *Third stream is
supported under certain settings. |
| Video Compression |
Main stream: H.265/H.264/H.264+/H.265+, Sub-stream:
H.265/H.264/MJPEG, Third stream: H.265/H.264, *Third stream is supported
under certain settings. |
| Video Bit Rate |
32 Kbps to 16 Mbps |
| H.264 Type |
Baseline Profile,Main Profile,High Profile |
| H.265 Type |
Main Profile |
| Scalable Video Coding (SVC) |
H.264 and H.265 encoding |
| Bit Rate Control |
CBR,VBR |
| Region of Interest (ROI) |
1 fixed region for main stream and sub-stream |
| Target Cropping |
Yes |
| Audio |
Audio Compression |
-2U: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Audio Bit Rate |
-2U: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps
(G.726)/32 to 160 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps
(AAC-LC) |
| Audio Sampling Rate |
-2U: 8 kHz/16 kHz/32 kHz/48 kHz |
| Environment Noise Filtering |
-2U: Yes |
| Network |
Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP,
NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS,
PPPoE, SNMP, WebSocket, WebSockets |
| Simultaneous Live View |
Up to 6 channels |
| API |
ONVIF (Profile S, Profile G),ISAPI,SDK,ISUP |
| Security |
Password protection, complicated password, HTTPS encryption, IP
address filter, Security Audit Log, basic and digest authentication for
HTTP/HTTPS, TLS 1.1/1.2/1.3, WSSE and digest authentication for Open
Network Video Interface |
| User/Host |
Up to 32 users 3 user levels: administrator, operator, and user |
| Client |
iVMS-4200,Hik-Connect,Hik-Central |
| Network Storage |
NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR), Together with
high-end Hikvision memory card, memory card encryption and health
detection are supported. |
| Web Browser |
Plug-in required live view: IE 11, Plug-in free live view: Chrome
80+, Firefox 80+, Edge 89+, Safari 13+, Local service: Chrome 80+,
Firefox 80+, Edge 89+, Safari 13+ |
| Image |
Image Parameters Switch |
Yes |
| Day/Night Switch |
Day,Night,Auto,Schedule |
| Wide Dynamic Range (WDR) |
120 dB |
| SNR |
≥ 52 dB |
| Image Enhancement |
BLC,HLC,3D DNR |
| Privacy Mask |
8 programmable polygon privacy masks |
| Interface |
Ethernet Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
| On-Board Storage |
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB |
| Reset Key |
Yes |
| Audio |
Built-in Microphone: -2U: Arrayed dual-microphone |
| Event |
Basic Event |
Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception |
| Linkage |
Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,trigger capture |
| Deep Learning Function |
Perimeter Protection |
Line crossing, intrusion Support alarm triggering by specified target types (human and vehicle) |
| General |
Power |
12 VDC ± 25%, 0.5 A, max. 6 W,reverse polarity protection,Ø5.5 mm coaxial power plug, PoE: IEEE 802.3af, Class 3, max. 7.5 W |
| Material |
Metal |
| Dimension |
Ø74.4 mm × 176.3 mm (Ø2.93" × 6.94") |
| Package Dimension |
234 mm × 120 mm × 117 mm (9.21" × 4.72" × 4.61") |
| Weight |
Approx. 515 g (1.1 lb.) |
| With Package Weight |
Approx. 760 g (1.7 lb.) |
| Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Startup and Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Language |
33 languages: English, Russian, Estonian, Bulgarian, Hungarian,
Greek, German, Italian, Czech, Slovak, French, Polish, Dutch,
Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish,
Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese,
Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil),
Ukrainian |
| General Function |
Heartbeat,mirror,flash log,password reset via email,pixel counter,anti-banding |
| Approval |
EMC |
CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC
61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021, RCM: AS/NZS
CISPR 32: 2015, IC: ICES-003: Issue 7, KC: KN32: 2015, KN35: 2015 |
| Safety |
CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, BIS:
IS 13252 (Part 1): 2010/IEC 60950-1: 2005, LOA: IEC/EN 60950-1 |
| Environment |
CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006 |
| Protection |
IP67: IEC 60529-2013 |
