  2. Cudy 8-Port Gigabit Industrial PoE Switch with 2 Gigabit SFP Port

Cudy 8-Port Gigabit Industrial PoE Switch with 2 Gigabit SFP Port

https://live-linkserve.odoo.com/web/image/product.template/63243/image_1920?unique=11eb8a9
(0 review)

3,205.00 MVR 3205.0 MVR 3,205.00 MVR GST Included

2,967.59 MVR GST Included

Not Available For Sale

    This combination does not exist.

    ADD TO CART ADD TO QUOTE
    BUY NOW
    Contact Us

    Terms and Conditions

    Description

    Specifications

    Model VersionIG1008ES2 1.0
    Interfaces1.25G SFP Slots2
    Gigabit RJ45 Ports8
    Shielded RJ45 PortTrue
    VLAN Mode Ports#1~#8 by default, configurable when the Web mode is activated
    LED
    • Power 1
    • Power 2
    • Link/ACT of Each Ethernet Port
    Power InterfacesPower Input Terminal
    Physical Buttons
    • Reset Button
    • Web On/Off
    • VLAN On/Off
    • Broadcast Storm Prevention On/Off
    Physical Buttons NoteWhen Web On/Off is enabled, the other On/Off toggles will be ignored by the system.
    PerformanceCopper Speed and Distance
    • Cat. 3 or higher cable: 100 meters at 10 Mbps
    • Cat. 5 or higher cable: 100 meters at 100 Mbps
    • Cat. 5e or higher cable: 100 meters at Gigabit
    Optical Spec and DistanceDepends on the Installed Optical Module
    MAC Address Table4096
    Max Switching Capacity21 Gbps
    Max Forwarding Rate14.88 Mpps
    Jumbo Frame16 KB
    Packet Buffer1.5 Mbit
    PowerPower MethodsDC via Terminal Block
    Power RedundancyDual Inputs
    Power Input9.6-60V⎓
    Max Power Consumption6.0W
    Idle Power Consumption0.6W
    Polarity Reverse ProtectionTrue
    Short Circuit ProtectionTrue
    Switching802.3 Protocols
    • 802.3x Flow Control
    • 802.3i 10BASE-T
    • 802.3u 100BASE-TX
    • 802.3ab 1000BASE-T
    • 802.3z 1000BASE-X
    • 802.3az Power Saving
    802.1 Protocols
    • 802.1p: LAN Layer 2 QoS/CoS
    • 802.1q: VLAN Bridge Operation
    • 802.1ab: LLDP/LLDP-MED
    Port Management
    • Port On/Off
    • Port Negotiation Speed
    • Port Trunk (Static Aggregation)
    • Port Mirror
    • Data Rate Limit
    • Jumbo Frame Settings
    • Storm Control
    • Traffic Monitor
    • MAC Address Management
    • EEE (802.3az)
    Port Mirror Sessions2
    Port Trunk Groups2
    Max Port Num per Port Trunk Group4
    L2 Features
    • IGMP Snooping
    • Loop Prevention
    • DHCP Snooping
    • LLDP Config and Neighbors
    • MTU VLAN
    • Port-Based VLAN
    • 802.1Q VLAN
    • DSCP QoS
    • 802.1p QoS
    • Port-Based QoS
    ReliabilityGrounding MethodsGrounding Point
    SafetyIEC/EN 62368
    EMCEN55032 Class A
    EN55035 Class A
    EMIFCC 47 CFR Part 15B Class A
    EMSIEC/EN 61000-4-2, Level 4 ESD: Contact: 8kV; Air: 15kV
    IEC/EN 61000-4-3, Level 4 RS: 80 MHz to 1 GHz: 30 V/m
    IEC/EN 61000-4-4, Level 4 EFT: Power: 2kV; RJ45: 4kV
    IEC/EN 61000-4-5, Level 4 Surge: Power: DM 2kV, CM 4kV; RJ45: CM 6kV
    IEC/EN 61000-4-6, Level 3 CS: 10V
    IEC/EN 61000-4-8, Level 5 PFMF
    IEC/EN 61000-4-9, Level 5 PMF
    IEC/EN 61000-4-10, Level 5 DOMF
    EMS NoteThe levels listed in each EMS field are the highest level defined in the IEC/EN standard.
    ShockIEC 60068-2-27
    VibrationIEC 60068-2-6
    Free FallIEC 60068-2-32
    EnvironmentOperating Temperature: -40 ℃ ~ 75 ℃ (-40 ℉ ~167 ℉)
    Storage Temperature: -40 ℃ ~ 85 ℃ (-40 ℉ ~ 185 ℉)
    Operating Humidity: 5% ~ 95% non-condensing
    Storage Humidity: 5% ~ 95% non-condensing
    SystemControl MethodsConfig Web Page
    Firmware UpgradeLocal Upgrade
    ReliabilityBackup and Restore
    Diagnostic Tools
    • Cable Status/Length Diagnosis
    • Ping
    Languages
    • English
    • Bengali
    • German
    • Spanish
    • French
    • Portuguese
    • Russian
    • Arabic
    • Indonesian
    • Hindi
    • Urdu
    • Traditional Chinese
    • Simplified Chinese
    MechanicalDimensionDevice:
    47.5×103×144 mm
    1.87×4.06×5.67 inches
    Mounting Space:
    47.5×147×165 mm
    1.87×5.79×6.5 inches
    Casing MaterialAluminum
    Ingress ProtectionIP40
    InstallationDIN-Rail
    Package Content
    • IG1008ES2
    • Installation Guide
    Ordering InformationRetail Package Dimension207×154×75 mm
    8.15×6.06×2.95 inches
    Units per Carton20
    Carton Dimension43.9×40.5×33.1 cm
    17.28×15.94×13.03 inches
