Description
Specifications
| Specification | Details |
|---|---|
| Capacity | 1 TB |
| Form Factor | M.2 2280 |
| NAND Flash | 3D NAND |
| Controller | Phison PS5026 E26 |
| Interface | PCIe Gen5 ×4 |
| Dimensions (L × W × H) | 80.6 × 24.2 × 17.9 mm (3.17 × 0.95 × 0.7 in) |
| Weight | 57.1 g (2.01 oz) |
| Sequential Read (Max) | Up to 10,000 MB/s* |
| Sequential Write (Max) | Up to 10,000 MB/s* |
| 4K Random Read IOPS (Max) | Up to 1,400K* |
| 4K Random Write IOPS (Max) | Up to 1,400K* |
| Operating Temperature | 0 °C to 70 °C |
| Storage Temperature | −40 °C to 85 °C |
| Shock Resistance | 1,500 G / 0.5 ms |
| MTBF | 1,600,000 hours |
| Endurance (TBW) | 1,400 TB** |
| Warranty | 5-year limited warranty |
