Specifications
Specifications
Physical Characteristics
| Dimensions | 5.7 in. H x 3.4 in. W x 3.3 in. D 14.5 cm. H x 8.6 cm. W x 8.3 cm. D |
| Weight | 11.2 oz. / 318.0 g |
| Input Voltage Range | 4.5 to 5.5 VDC host powered; 4.5 to 5.5 VDC external power supply |
| Operating Current at Nominal Voltage (5.0V) | Presentation mode: 335mA Trigger mode: 350mA |
| Standby Current (Idle) at Nominal Voltage (5.0V) | Presentation mode: 135mA Trigger mode: 75mA |
| Color | Alpine White, Midnight Black |
| Supported Host Interfaces |
USB Certified, RS232, Keyboard Wedge, TGCS (IBM) 46XX over RS485 |
| Keyboard Support | Supports over 90 international keyboards |
| TAA Compliance | Trade Agreement Act Compliant (optional on select configurations) |
| Electronic Article Surveillance | Compatible with Checkpoint EAS deactivation system |
| User Indicators | Good decode LEDs, rear view LEDs, beeper (Adjustable tone and volume) |
Performance Characteristics
| Swipe Speed (Presentation) | Up to 120 in./305 cm. per second for 13 mil UPC in optimized mode |
| Light Source | Aiming pattern: circular 617 nm amber LED |
| Illumination | 660 nm Hyper Red LED |
| Imager Field of View | 52° H x 33° V nominal |
| Image Sensor | 1280 x 800 pixels |
| Minimum Print Contrast | 15% |
| Skew Tolerance | +/-60° |
| Pitch Tolerance | +/-60° |
| Roll Tolerance | 360° |
Imaging Characteristics
| Graphics Format Support | Images can be exported as bitmap, JPEG or TIFF |
| Image Quality | 109 PPI on a 4.1 in. x 5.8 in./A6 sized document |
User Environment
| Operating Temperature | 32.0° F to 122.0° F / 0.0° C to 50.0° C |
| Storage Temperature | -40.0° F to 158.0° F / -40.0° C to 70.0° C |
| Humidity | 5% to 95% RH, non-condensing |
| Drop Specification | Designed to withstand multiple drops at 5.0 ft. / 1.5 m to concrete |
| Tumble Specification | Designed to withstand 1,000 tumbles in 1.5 ft. /0.5 m tumbler |
| Environmental Sealing | IP52 |
| Electrostatic Discharge (ESD) | ESD per EN61000-4-2, +/-15 KV Air, +/-8 KV indirect |
| Ambient Light Immunity | 0 to 10,000 foot-candles/0 to 107,700 Lux |
Â
Regulatory
| Environmental | EN 50581:2012 RoHS 2011/65/EU (2015/863) - EN 50581:2012, IEC 63000 REACH 1907/2006 |
| Electrical Safety | IEC 62368-1 2nd ed. EN 62368-1:2014/AC:2015 UL/IEC 60950-1, 2nd ed. CAN/CSA C22.2 No.60950-1, 2nd ed. |
| LED Safety | IEC 62471:2006 (Ed.1.0) EN 62471:2008 (LED) |
| EMI/RFI | FCC 47 CFR Part 15B, ICES-003, EN55032, EN55024, EN55035, VCCI, and SABS |
Accessories
| Multi-mount bracket, locking-mount bracket |
Symbol Decode Capability1
| 1D | Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32 (Italian Pharma) |
| 2D | PDF417, Micro PDF417, Composite Codes, TLC-39, Aztec, DataMatrix, MaxiCode, QR Code, Micro QR, Han Xin, Postal Codes, securPharm, DotCode, Dotted DataMatrix |
| OCR | OCR-A, OCR-B, MICR, US currency |
| Digimarc | Available on specific models only |
| Minimum Element Resolution | Code 39: 3 mil; Code 128: 3 mil; Data Matrix: 5 mil; QR Code: 5 mil |
Decode Ranges (Typical)2
| Symbology/Resolution | Near/Far |
| Code 39: 3 mil | 0 in./0 cm — 2.5 in./6.35 cm |
| Code 39: 5 mil | 0 in./0 cm — 5.0 in./12.7 cm |
| Code 39: 20 mil | 0 in./0 cm — 11.0 in./27.9 cm |
| Code 128: 3 mil | 0 in./0 cm — 2.0 in./5.1 cm |
| Code 128: 5 mil | 0 in./0 cm — 4.0 in./10.2 cm |
| PDF 417: 6.7 mil | 0 in./0 cm — 4.0 in./10.2 cm |
| UPC: 13 mil (100%) | 0 in./0 cm — 8.8 in./22.4 cm |
| Data Matrix: 10 mil | 0 in./0 cm — 4.5 in. /11.4 cm |
| QR: 20 mil | 0 in./0 cm — 7.5 in./19.1 cm |
