Description
Specifications
| Brand | HIKVISION |
| Range | VALUE |
| Image sensor | 1/2.4" Progressive Scan CMOS |
| Maximum resolution | 6 Megapixel (3200x1800) |
| Main Stream rate | 20 fps (3200x1800, 2688x1520, 1920×1080, 1280×720) [%VAR%] |
| Extra Stream rate | 20 fps (1280×720, 640×480, 640x360) |
| Compression | H.265+ / H.264+ / H.265 / H.264 |
| Bitrate | 32 Kbps ~ 16 Mbps |
| Lens | 2.8 mm |
| Viewing Angle (FOV) | H: 115°, V: 60°, D: 143° |
| Range performance | 64 m (D), 25 m (O), 12 m (R), 6 m (I) |
| Minimum illumination | Colour: 0.001 Lux @(F1.0, AGC ON) 0 Lux conIR |
| Supplementary lighting | Hybrid light: IR Range 30 m White light range 30 m |
| Day/Night | ColorVu: Color image 24 hours |
| Image improvements | WDR (120 dB), BLC, HLC, 3D-DNR, AGC, AWB, ROI, Mirror function, Privacy masking |
| Motion Detection | Motion detection 2.0 with human and vehicle classification applied in motion detection. |
| Audio | Integrated microphone |
| Audio type | Mono |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC |
| Audio bit rate | 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC) |
| Internal memory | Does not have |
| Network interface | Ethernet 10/100M BaseT |
| Remote access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200 and Hik-Central |
| Interoperability | ONVIF (Profiles S, T, G), ISAPI, SDK |
| Power | DC 12 V / 550 mA / 6.6 W max. PoE IEEE802.3af |
| Degree of protection | Weatherproof IP67 Vandal proof IK08 |
| Material | Base: Metallic Cover: Plastic |
| Temp. operation | -30º C ~ +60º C |
| Dimensions | Ø 121.5 mm x 97.6 mm (H) |
| Base dimensions | Ø base 121.5 mm / Ø entre tornillos 104.7 mm / 3 tornillos |
| Weight | 550 g |
