Description
Specifications
Microphone | |
Type | electret |
Amount | 2 |
Frequency Response | 100 Hz to 20 kHz |
Sensitivity | -42 dBV/Pa |
Sampling Rate | 48 kHz |
Quantization Bits | 16 bit |
Speaker | |
Rated Power | 25 W |
Impedance | 8 Ω |
Max. Acoustic Pressure | 124 dBSPL |
Sensitivity(1 m, 1 W) | 110 dB |
Direction | 70° horizontal by 100° vertical |
Frequency Response | 300 Hz to 8 kHz |
SNR | 83 dB |
Function | |
Audio Algorithm | AEC, AGC, ANS, DRC |
Audio Bit Rate | G.711ulaw(64 Kbps)/G.711alaw(64 Kbps)/MP3(128 Kbps) Sampling bit width: 16 bits |
Audio File Format | MP3, WAV |
NTP Timing | Support |
Broadcast | Regular broadcast, live broadcast, emergency broadcast |
Two-Way Audio | Support |
Speech Synthesis | Language Type: English, Russian, Spanish, Japanese, Thai, Portuguese (Brazil) |
Network | |
Network Protocol | IPv4, HTTP, HTTPS, SIP, SSL/TLS, DNS, NTP, TCP, UDP, IGMP, ICMP, DHCP, ARP, SSH |
Interface Protocol (API) | ISAPI, ISUP, SIP, RTP, ONVIF |
Client | Hik-Connect, ivms/4200, HikCentral Professional, Hik-Partner Pro, NVR, MileStone |
Communication | |
Communication Method | Support wired network communication |
Interface | |
Alarm | Alarm input ×1 |
Ethernet Interface | RJ45 10 M/100 M Adaptive Ethernet port × 1 |
Power Output | 12 VDC, 25 mA(max.) |
Local Storage | Built-in 4 GB EMMC (Audio file storage is 1 GB.) |
API | ISAPI, ISUP, SIP, ONVIF |
Reset | Support |
General | |
Material | Metal |
Operating Temperature | -30 °C to 60 °C (-22 °F to 140 °F) |
Operating Humidity | ＜90% (No condensation) |
Language | 9 languages: English, French, Spanish, German, Italian, Russian, Japanese, Thai, Portuguese (Brazil) |
Dimension | 175 mm × 237 mm × 272 mm (6.9" × 9.3" × 10.7") |
Power | 24 VDC, 1167mA, 28W |
Package Dimension | 310 mm × 245 mm × 400 mm (12.2" × 9.6" × 15.6") |
Weight | Approx. 2.1 kg (4.63 lb.) |
Color | White |
With Package Weight | Approx. 3.4 kg (7.50 lb.) |
Packing List | Device × 1 Threading cap × 1 Regulatory Compliance and Safety Information × 1 |
Approval | |
Protection | IP67 |
EMC | CE-EMC: EN 55032:2015+A11:2020+A1:2020, EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019+A2:2021, EN 55035:2017+A11:2020 RCM: AS/NZS CISPR 32: 2015 IC: ICES-003: Issue 7 |
Safety | CB: IEC 62368-1:2014 CE-LVD: EN 62368-1:2014/A11:2017 |
Environment | CE-RoHS: 2011/65/EU WEEE: 2012/19/EU Reach: Regulation (EC) No 1907/2006 |
