Description
Specifications
System Parameters
| Specification | Details |
|---|---|
| Operating System | Embedded Android 9.0 Operating System |
| ROM | 4 GB |
| RAM | 2 GB |
| CPU | Embedded Processor |
Display Parameters
| Specification | Details |
|---|---|
| Screen Size | 7-inch |
| Operation Method | Touch Screen |
| Display Type | Colorful IPS Screen |
| Resolution | 1024 × 600 |
Video Parameters
| Specification | Details |
|---|---|
| Lens | 1 |
| Camera Resolution | 2 MP |
| Video Compression Standard | H.264 |
| Video Decoding | H.264 |
| Video Decoding Resolution | QVGA / CIF / VGA / 4CIF / 720P / 1080P |
Audio Parameters
| Specification | Details |
|---|---|
| Audio Compression Standards | G.711A/U, G.729A/B, iLBC, G.722, Opus |
| Audio Input | HD Voice Microphone HAC Handset |
| Audio Output | HD Voice Speaker (Handset / Hands-Free) Frequency Response: 0 ~ 7 kHz |
| Audio Quality Features | Full-Duplex Acoustic Echo Canceller (AEC) Noise Reduction (NR) Packet Loss Concealment (PLC) |
| Volume Adjustment | Adjustable |
Capacity
| Specification | Details |
|---|---|
| Communication Lines | 20 SIP Lines |
| Contact Capacity | Local Phonebook: 2000 Entries Remote Phonebook (XML / LDAP): 2000 Entries |
| Call Log Capacity | Incoming / Outgoing / Missed Calls 1000 Entries |
Network Parameters
| Specification | Details |
|---|---|
| Communication Protocols | SIP v1 (RFC2543), SIP v2 (RFC3261) over UDP / TCP / TLS RTP / RTCP / SRTP STUN, DHCP, IPv6, PPPoE, L2TP, OpenVPN, SNTP, FTP / TFTP, HTTP / HTTPS, TR-069 |
| Wired Network | 10 / 100 / 1000 Mbps Self-Adaptive |
| Wi-Fi Standard | N/A |
Device Interfaces
| Specification | Details |
|---|---|
| Network Interface | 2 × RJ-45 10 / 100 / 1000 Mbps Self-Adaptive |
| TF Card | Up to 128 GB (Reserved) |
| USB | USB 2.0 × 1 (Reserved) |
| Power Supply Input | DC Power Input |
| Communication Interface | 2 × RJ-9 (Handset ×1, Headset ×1) |
| Video Output | HDMI ×1 (Reserved) |
General
| Specification | Details |
|---|---|
| Buttons | 5 Keys Total • 1 Home Key • 1 Return Key • 1 Hands-Free Key • 2 Volume Control Keys (Up / Down) |
| Installation | Desktop Stand Wall-Mounted |
| Indicator | Red Status LED for Call & Message Waiting |
| Working Temperature | 0 °C to 45 °C (32 °F to 113 °F) |
| Working Humidity | 10% to 95% (Non-Condensing) |
| Dimensions | Desktop (Angle 1): 254.8 × 154.9 × 202.8 mm Desktop (Angle 2): 254.8 × 167.8 × 182.4 mm Wall-Mounted: 254.8 × 118.4 × 206.9 mm |
| Power Supply | IEEE 802.3af Standard PoE 12 VDC |
| Power Consumption | PoE: 3.11 ~ 10.76 W Adapter: 2.38 ~ 8.4 W |
| Application Environment | Indoor |
| Languages | English, Galician, Simplified Chinese, Traditional Chinese, Danish, Czech, Russian, Italian, French, German, Hebrew, Spanish, Catalan, Turkish, Hungarian, Slovenian, Korean, Dutch, Ukrainian, Portuguese, Polish, Filipino, Indonesian, Latvian, Lithuanian, Malay, Romanian, Slovak, Finnish, Swedish, Vietnamese, Greek, Bulgarian, Serbian, Arabic, Persian, Thai |
