Description
Specifications
| Specification | Details |
|---|
| Model | DS‑KP8000‑HE1 |
| System Parameters |
| Operating System | Embedded Linux operation system Hikvision |
| ROM | 128 MB Hikvision |
| RAM | 94 MB Hikvision |
| CPU | Embedded processor Hikvision |
| Display Parameters |
| Screen Size | 2.8‑inch Hikvision |
| Operation Method | Physical keys Hikvision |
| Display Type | Colourful screen Hikvision |
| Display Resolution | 320 × 240 Hikvision |
| Video Parameters |
| Video Decoding | H.264 hardware decoding Hikvision |
| Video Decoding Resolution | QVGA / CIF / VGA / 4CIF / 720P / 1080P Hikvision |
| Audio Parameters |
| Audio Compression | G.711A/U, G.729AB, iLBC, G.722, Opus Hikvision |
| Audio Input | HD voice microphone; HAC handset Hikvision |
| Audio Output | HD voice speaker (handset / hands‑free), 0 ~ 7 kHz frequency response Hikvision |
| Audio Quality | Voice Activity Detection (VAD), Comfort Noise Generation (CNG), Background Noise Estimation (BNE), Noise Reduction (NR), voice quality monitoring Hikvision |
| Volume Adjustment | Adjustable Hikvision |
| Capacity |
| Communication Lines | 6 SIP Lines Hikvision |
| Contact Capacity | Local phonebook: 1000 entries Remote phonebook (XML/LDAP): 1000 entries Hikvision |
| Call Log Capacity | In/Out/Missed: 600 entries Hikvision |
| Network Parameters |
| Communication Protocol | SIP v1 (RFC2543), v2 (RFC3261) over UDP/TCP/TLS, RTP/RTCP/SRTP, STUN, DHCP, IPv6, PPPoE, L2TP, OpenVPN, SNTP, FTP/TFTP, HTTP/HTTPS, TR‑069 Hikvision |
| Wired Network | 10/100 Mbps self‑adaptive Hikvision |
| Wi‑Fi | NA Hikvision |
| Device Interfaces |
| Network Interface | 2 × RJ45 10/100 Mbps self‑adaptive Hikvision |
| Power Supply Input | DC power input / IEEE 802.3af Standard PoE / 12 VDC Hikvision |
| Communication Interface | 2 × RJ‑9: handset ×1, headset ×1 Hikvision |
| Buttons & Controls |
| Keys | 37 keys: 3 line keys (BLF) with LED indicator; 2 keys with LED indicator (MWI/handset); 8 function keys (Hold, Transfer, Conference, Contact, CallLog, Status, Redial, Mute); 4 soft‑keys; 4 navigation; 1 OK; 12 phone digit keys; 2 volume control; 1 hands‑free key Hikvision |
| Indicator | Red status indicator light for call and message waiting Hikvision |
| General |
| Working Temperature | 0 °C to 45 °C (32 °F to 113 °F) Hikvision |
| Working Humidity | 10% to 95% (no‑condensing) Hikvision |
| Dimensions | Desktop stand (45°): 169 × 186.3 × 174.5 mm Desktop stand (50°): 169 × 177.6 × 183.7 mm Wall‑mounted: 169 × 115.6 × 212.5 mm Hikvision |
| Power Consumption | PoE: 1.78 W ~ 5.92 W; Adapter: 1.28 W ~ 4.31 W Hikvision |
| Application Environment | Indoor Hikvision |
| Supported Languages | English, Simplified Chinese, Traditional Chinese, Russian, Italian, French, German, Hebrew, Spanish, Catalan, Basque, Galician, Turkish, Hungarian, Slovenian, Czech, Korean, Dutch, Ukrainian, Portuguese, Polish |
