Description
Specifications
| Camera type ℹ️ | Single camera |
| Sensor type ℹ️ | CMOS |
| Optical sensor size ℹ️ | 25.4 / 2.8 mm (1 / 2.8") |
| Zoom capability ℹ️ | ✅ |
| Digital zoom ℹ️ | 3x |
| Field of view (FOV) angle | 118.8° |
| Horizontal field of view | 109.9° |
| Vertical field of view | 74.6° |
| Signal-to-Noise Ratio (SNR) ℹ️ | 60 dB |
| F-number (relative aperture) | 2.5 |
| White balance ℹ️ | Auto, Daylight, Locked WB, Natural, Sodium lamp |
| Back Light Compensation (BLC) | ✅ |
| Number of camera presets | 5 |
| PTZ control | ✅ |
| Slowest camera shutter speed ℹ️ | 0.00001 s |
| Privacy camera | ✅ |
Video
| Maximum video resolution ℹ️ | 3840 x 2160 pixels |
| Maximum frame rate ℹ️ | 60 fps |
| HD type ℹ️ | 4K Ultra HD |
| Supported video modes ℹ️ | 1080p |
| Video formats supported ℹ️ | H.264, MJPG |
| High Dynamic Range (HDR) supported | ✅ |
Design
| Product colour ℹ️ | Black, Grey |
| Mounting type ℹ️ | Stand |
| LED indicators | Power, Status |
Ports & interfaces
| HDMI ports quantity ℹ️ | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity ℹ️ | 1 |
| Ethernet LAN (RJ-45) ports ℹ️ | 1 |
| DC-in jack ℹ️ | ✅ |
Power
| Power source type ℹ️ | DC |
| DC input voltage | 12 V |
| Power consumption (max) ℹ️ | 12.06 W |
Operational conditions
| Operating temperature (T-T) ℹ️ | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Packaging content
| Remote control included ℹ️ | ✅ |
| Remote control batteries included | ✅ |
| Cables included | USB |
| USB cable length | 2 m |
| Screws included | ✅ |
| AC adapter included | ✅ |
| Mounting brackets included | ✅ |
Audio
| Built-in microphone ℹ️ | ✅ |
| Number of microphone arrays | 8 |
| Built-in speaker(s) ℹ️ | ✅ |
| Speaker frequency range | 150 - 18000 Hz |
| Microphone pick-up range | 6 m |
| Supported sample rates | 48 kHz |
Performance
| Bluetooth ℹ️ | ✅ |
| Auto framing | ✅ |
| Auto-tracking | ✅ |
| Plug and Play ℹ️ | ✅ |
Weight & dimensions
| Width ℹ️ | 616 mm |
| Depth ℹ️ | 104.2 mm |
| Height ℹ️ | 145 mm |
Packaging data
| Package width ℹ️ | 727 mm |
| Package depth ℹ️ | 213 mm |
| Package height ℹ️ | 227 mm |
| Package weight ℹ️ | 5.36 kg |
