Description
Specifications
| Video and Audio | |
| IP Video Input | 8-ch |
| Incoming Bandwidth | 60 Mbps |
| Outgoing Bandwidth | 60 Mbps |
| HDMI Output | 1920x1080/60Hz:1600x1200/60Hz:1280x1024/60Hz:1280x720/60Hz |
| Decoding | |
| Decoding Format | H.265, Smart265, H.264, Smart264 |
| Recording Resolution | 4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Synchronous Playback | 4-ch |
| Decoding Capability | 4-ch@1080p (25 fps) |
| Stream Type | Video, Video & Audio |
| Audio Compression | G.711ulaw/G.711alaw/G.722/G.726 |
| Network | |
| Remote Connection | 128-ch |
| Network Protocol | TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, NFS, iSCSI, ISUP, UPnP„¢, HTTP, HTTPS |
| Network Interface | 1 RJ-45 10/100 Mbps self-adaptive Ethernet interface |
| PoE | |
| Interface | 8, RJ-45 10/100 Mbps self-adaptive Ethernet interface |
| Power | = 58 W |
| Standard | IEEE 802.3 af/at |
| Auxiliary Interface | |
| Capacity | 2TB SSD (pre-installed) |
| USB Interface | Rear panel: 2 x USB 2.0 |
| General | |
| Power Supply | 48VDC:1.36A |
| Consumption | = 10 W (with SSD) |
| Working Temperature | -10 °C to 50 °C (14 °F to 122 °F) |
| Working Humidity | 10 to 90 % |
| Dimension (W x D x H) | 225 x122 x27 mm (8.9" x 4.8" x 1.1") |
| Weight | = 0.57 kg |
