Description
Specifications
Technical Details
| Operation Mode | ON-OFF |
|---|---|
| Current Rating | 30 Amps |
| Operating Voltage | 250 Volts |
| Contact Type | Normally Open |
| Connector Type | Pin Header |
| Brand | JINDING |
| Terminal | Screw |
| Item dimensions L x W x H | 32 x 25 x 30 Millimeters |
| Circuit Type | 2-way |
| Actuator Type | Push Button |
| Contact Material | Copper, Brass |
| International Protection Rating | IP54 |
| Number of Positions | 2 |
| Specification Met | TUV, CE, CQC |
| Controller Type | Push Button |
| Connectivity Protocol | Bluetooth |
| Colour | Red |
| Wattage | 3750 Watts |
| Number of Items | 1 |
| Manufacturer | JINDING |
| Country of Origin | USA |
| Model number | JD03-A1 |
| Item Weight | 41 g |
| Product Dimensions | 3.2 x 2.5 x 3 cm; 41 g |
| Item model number | JD03-A1 |
| Item Height | 30 Millimeters |
| Item Width | 25 Millimeters |
| Voltage | 125 Volts |
| AC Adapter Current | 30 Amps |
| Are batteries included? | No |
Additional Information
| ASIN | B081QH29D9 |
|---|---|
| Date First Available | 8 June 2024 |
| Manufacturer | JINDING |
| Item Dimensions LxWxH | 32 x 25 x 30 Millimeters |
Product description
2pcs 6Pins 30A 125V/250V Large Current Rocker Power Switches for Inverter Welding Machine JD03-A1 with Connecting Piece, 2 Positions, Red Color
1. Model number: JD03-A1.
2. Terminals: 6 pins with connecting piece.
3. Working Current/voltage: 30A, 125V/250V, Withstand voltage: AC1500V(50/60HZ)/1Min
4. Life time: 50,000 times, T85/55.
5. Apply to: Inverter Welding Machine
6. Contact resistance: 50 (mΩ), insulation resistance: 100 (MΩ).
7. Certificate: TUV, CE, TUV, CQC.
8. Packing: 2 pieces push button switches
