Description
Specifications
Model |
TC-2500 |
|
Output power (1KHz/THD≤1%)
|
Stereo 8Ω: 2*500W; 4Ω: 2*800W; 2Ω: 2*1300W; Bridge 16Ω: 1000W; 8Ω: 1600W; 4Ω: 2600W; |
|
Connector |
XLR interface |
|
Voltage gain (@1KHz) |
36dB |
|
Input sensitivity |
2.2dBU(1V), 8.2dBU(2V) |
|
Input impedance |
10KΩ unbalanced, 20KΩ balanced |
|
Frequency response (@1W power) |
20-20KHz/±1dB |
|
THD+N (@1/8 power) |
≤0.01% |
|
SNR (A-weighted) |
≥102dB |
|
Damping coefficient (@1KHz) |
≥200@ 8 ohms |
|
Separation (@1KHz) |
≥85dB |
|
Protection method |
Over-voltage protection, under-voltage protection, over-current protection, DC protection, short circuit protection |
|
Indicator light |
Power, Protection, Signal, Distortion |
|
Cooling method |
Fan cooling |
|
Power supply |
~ 220 50Hz |
|
Overall power consumption |
450W |
|
Dimension (L×W×H) |
484×353×44mm |
|
Weight |
6.2kg |
|
Notes: Output power: according to CEA-2006-B/CEA-490-A standard using 20ms pulse 1kHz sine wave measured under 1% total harmonic distortion. Overall power consumption: according to GB4943.1-2022 test method: measured under 1kHz sine wave rated load 1/8 power conditions.
|
