Description
Specifications
Model |
|
TI-1206S |
TI-2406S |
TI-3506S |
TI-5006S |
|
Amplifier Section (Load 100V Output) |
Rated Output Power (THD 1%) |
120W(RMS) |
240W |
350W |
500W |
|
Speaker Zone 1~6 Output |
25W MAX |
50W MAX |
70W MAX |
85W MAX |
|
|
Mic Input Section (Mic 1~4 In@1KHz) |
Input Sensitivity/Impedance |
5mV 600Ω/350mV 10KΩ BAL |
|||
|
S/N Ratio |
Better than 75dB |
||||
|
Frequency Response (±3dB) |
80Hz~16KHz |
||||
|
Tone Control (Bass:100Hz, Treble:10KHz) |
±10dB |
||||
|
Phantom Power |
+ 48V |
||||
|
Line Input Section (Mic 1~2 In@1KHz) |
Input Sensitivity/Impedance |
350mV/47KΩ |
|||
|
S/N |
Better than 80dB |
||||
|
Frequency Response (±3dB) |
80Hz~16KHz |
||||
|
Tone Control (Bass: 100Hz,Treble:10KHz) |
±10dB |
||||
|
Tel Audio Input |
Input Sensitivity/Impedance |
775mV/10KΩ |
|||
|
S/N |
Better than 75dB |
||||
|
Frequency Response (±3dB) |
50Hz~16KHz |
||||
|
EMC Audio Input |
Input Sensitivity/Impedance |
775mV/10KΩ |
|||
|
S/N |
Better than 75dB |
||||
|
Frequency Response (±3dB) |
80Hz~16KHz |
||||
|
Pre Amp Out(Mic 1~4, Line 1~2, Tel In, Remote In) |
1V/600Ω |
||||
|
Remote MIC Sensitivity/Impedance |
775mV/10KΩ |
||||
|
THD |
≤ 0.1% at 1KHz, 1/3 rated power |
||||
|
Power Supply |
~110V/60Hz or ~230V/50Hz & DC 24V |
||||
|
Power Consumption |
210W |
380W |
530W |
750W |
|
|
Weight |
6.7Kg |
7.2Kg |
8.6Kg |
9.0Kg |
|
|
Dimensions |
484x310x88 mm |
