Description
Specifications
Model |
T-328 |
|
MIRCOPHONE INPUT |
|
|
Sensitivity |
±5 mV/600Ω |
|
S/N Ratio |
>68dB |
|
Frequency Response |
100Hz~17KHz (+1, -3dB) |
|
Phantom Power |
+12V |
|
CONTROL |
|
|
Bass |
±12dB at 100Hz |
|
Treble |
±12dB at 10KHz |
|
Chime |
2 tone active for contact free in priority and BGM |
|
Normal Distortion |
>0.1% |
|
OPERATING CONDITION |
|
|
Power Supply |
DC 24V |
|
Dimensions |
216 x 141 x 52 mm |
|
Weight |
1.5Kg |
|
Max Number of Paging Console |
6 |
