Description
Specifications
Model |
T-10AP
|
T-20AP |
T-40AP
|
T-60AP
|
T-120AP
|
T-240AP
|
|
Rated Power Output |
10W |
20W |
40W |
60W |
120W |
240W |
|
Speaker Outputs |
70V, 100V & 4~16Ω |
|||||
|
Input Sensitivity & Impedance |
MIC1, 2, 3: 5mV/600Ω, Unbalanced TRS input |
|||||
|
MIC1: ±2.5mV/2KΩ |
||||||
|
TEL: ±175mV/10KΩ |
||||||
|
AUX: 350mV/10KΩ, Unbalanced RCA input |
||||||
|
Output Sensitivity & Impedance |
LINE OUT: 1V/470Ω, Unbalanced RCA output |
|||||
|
Overload Electromotive Force |
MIC 1, 2, 3: >10dB |
|||||
|
MIC1: >15dB |
||||||
|
AUX: >15dB, Unbalanced RCA input |
||||||
|
TEL: >12dB |
||||||
|
Tone |
Bass: ±10dB, Treble: ±10dB |
|||||
|
Frequency Response |
50Hz~16KHz (+1dB, -3dB) |
|||||
|
S/N Ratio |
MIC: 66dB, AUX: 80dB |
|||||
|
THD |
Less than 0.5% at 1KHz, 1/3 rated power |
|||||
|
Muting Function |
MIC 1 overrides other input signals with 30dB attenuation |
|||||
|
Cross talk |
≥50dB |
|||||
|
Phantom Power |
+48V |
|||||
|
Cooling |
Button-up convert automatic cool |
|||||
|
Protection |
High temp, overload & short-circuit |
|||||
|
Power Supply |
~110V-230V 50/60Hz |
|||||
|
Power Consumption |
20W |
40W |
70W |
100W |
200W |
340W |
|
Weight |
1.8kg |
3.56kg |
4.6kg |
7.8kg |
9.2kg |
11.5kg |
|
Dimensions |
200 x 153 x 45mm |
|||||
|
Finish |
Panel: aluminum plate, black |
|||||
|
Case: SPCC Panel |
