Description
Specifications
Model |
T-221AP |
|
Rated Power Output |
2x20W (THD10% @ 4Ω1KHz) |
|
Output Impedance |
4Ωor 8Ω |
|
Line Input Sensitivity |
200mV-2V/10KΩ |
|
Frequency Response |
50Hz~18KHz(±2dB) |
|
S/N Ratio |
≦85dB |
|
THD |
≤0.5% at 1KHz, 1/3 rated power |
|
Efficiency |
85% |
|
Controls |
Power, input sensitivity, gain control, bass & treble |
|
Indicators |
Power |
|
Protection |
Overload, high temp and short-circuit |
|
Power Supply |
DC 24V, power adapter is supplied compatible of 110V-240V |
|
Dimensions |
230x115x56.5mm |
|
Finish |
Panel: steel, black Case: steel, black |
