Description
Specifications
| Specification | Details |
|---|
| Model | DS‑7104NI‑Q1/4P/M |
| Product Type | Mini PoE Network Video Recorder (NVR) |
| IP Video Input | 4 channels |
| Max Resolution | Up to 6 MP |
| Video Compression | H.265+, H.265, H.264+, H.264 |
| Incoming Bandwidth | 40 Mbps |
| Outgoing Bandwidth | 60 Mbps |
| PoE Ports | 4 × RJ45 10/100 Mbps with PoE |
| PoE Standard | IEEE 802.3af / IEEE 802.3at |
| PoE Power | ≤ 36 W total |
| HDMI Output | 1 × HDMI, up to 1920 × 1080p |
| VGA Output | 1 × VGA, up to 1920 × 1080p |
| Video Output Mode | HDMI and VGA simultaneous |
| Recording Resolution | 6 MP / 4 MP / 3 MP / 1080p / 720p / VGA / CIF |
| Synchronous Playback | 4 channels |
| Decoding Capability | 4‑ch @ 1080p (30 fps) |
| Network Interface | 1 × RJ45 10/100 Mbps |
| Network Protocols | TCP/IP, DHCP, DNS, DDNS, NTP, RTSP, UPnP, SMTP, ONVIF |
| Remote Connections | Up to 16 users |
| SATA Interface | 1 × SATA HDD |
| HDD Support | Up to 6 TB |
| USB Interface | 2 × USB 2.0 |
| Alarm In/Out | N/A |
| Power Supply | 48 VDC, 1 A |
| Power Consumption | ≤ 10 W |
| Operating Temperature | –10 °C to +55 °C |
| Operating Humidity | 10% to 90% |
| Dimensions (W × D × H) | 265 × 223 × 48 mm |
| Weight | ≤ 1 kg |
