Description
Specifications
| Brand | HIKVISION |
| Range | PRO |
| Video format | HDTVI / HDCVI / AHD / CVBS / IP |
| Video Inputs | 8 Channel BNC, (HDTVI / HDCVI / AHD / CVBS) |
| Hybrid configuration | 8 additional IP CH: Up to 16 IP channels (8 Mpx), replacing all BNC channels |
| Main Stream Coding | 8 MP@8 fps/3K@12 fps/5 MP@12 fps/4 MP@15 fps/8 MP Lite@15 fps/3 MP@18 fps 1080p/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N) |
| Extra Stream Coding | WD1/4CIF/CIF@25 fps (P)/30 fps (N) |
| Decoding capacity | 24 channels 1080P@30fps |
| Total Bandwidth | 256 Mbps |
| Video Outputs | 1 HDMI 4K and 1 VGA, simultaneous 1 BNC CVBS |
| Resolution display | HDMI: 4K (3840x2160), 2K (2560x1440), 1920x1080, 1280x1024, 1280x720 / 60Hz VGA: 1920x1080, 1280x1024, 1280x720 / 60Hz CVBS: 704x576 (PAL) / 704x480 (NTSC) |
| Compression video | Analog: H.265+ / H.265 Pro / H.265 / H.264+ / H.264 IP: H.265+ / H.265 / H.264+ / H.264 |
| Entry Resolution | HDTVI: 8Mpx (12 fps), 3K (20~25 fps), 5Mpx (20 fps), 4Mpx (25~30 fps), 1080p (25~30 fps), 720p (25~30 fps) HDCVI: 8Mpx (12 fps), 3K (25 fps), 5Mpx (20 fps), 4Mpx (25~30 fps), 1080p (25~30 fps), 720p (25~30 fps) AHD: 5Mpx (20 fps), 4Mpx (25~30 fps),1080p (25~30 fps), 720p (25~30 fps) CVBS: PAL/NTSC |
| Audio inputs | 1 RCA Channel |
| Audio outputs | 1 RCA Channel |
| Two-way audio | Reusing the audio input |
| Audio compression | G.711u |
| Audio Bit Rate | 64 Kbps |
| Video Bit Rate | 32 Kbps at 10 Mbps |
| Alarm | It does not have |
| Simultaneous multifunction | Pentaplex: Direct, Recording, Playback, Backup and Remote Access |
| Motion detection | Motion detection 2.0 with classification of humans and vehicles applied in motion detection For the NVR: Available on all channels. * Motion detection and AcuSense cannot be enabled on a single device. |
| AcuSense | VCA rule-based perimeter protection with false alarm filter for human and vehicle detection applied on: Line Crossing, Area Intrusion. For the NVR: Available in up to 8 channels. * Motion detection and AcuSense cannot be enabled on a single device. |
| Facial recognition | Storage in up to 16 libraries. Comparison of faces in up to 4 CH. |
| Facial Detection | Facial detection photo search Up to 4 channels to capture image. |
| Recording method | Manual, Scheduled, Motion Detection |
| Internal storage | 2 HDD SATA 3.5" up to 12 TB each (not included) |
| Communication | 1 x USB 2.0 (front panel) / 2 x USB 3.0 (back panel) / RJ45 (Ethernet) 10/100/1000 Mbps / 1 x RS-485 |
| Remote Connections | 128 |
| Remote access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200 and Hik-Central |
| Food | DC 12 V, 3.3 A, ≤ 15 W (no HDD) |
| Operating Temperature | -10° ~ +55°C |
| Dimensions / Weight | 384 (W) x 317 (Fo) x 52 (Al) mm / ≤ 1.78 Kg (without HDD) |
