| Specifications |
|
| Model |
CS-H6-V100-1J5WF |
|
| Camera |
|
| Image Sensor |
1/2.7" Progressive Scan CMOS |
|
| Shutter Speed |
Self-adaptive shutter |
|
| Lens |
4mm@ F1.6, view angle:104° (Horizontal), 87° (Vertical), 53°(Diagonal) |
|
| PT Angle |
Pan: 353° , Tilt: 133° |
|
| Minimum Illumination |
0.51Lux @(F1.6, AGC ON), 0 Lux with IR |
|
| Lens Mount |
M12 |
|
| Day & Night |
IR-cut filter with auto-switching |
|
| DNR |
3D DNR |
|
| WDR |
Digital WDR |
|
| BLC |
Supports |
|
| Night Vision |
10 m |
|
| Video & Audio |
|
| Max. Resolution |
2880 × 1620 |
|
| Frame Rate |
Max:25fps; Self-Adaptive during network transmission |
|
| Video Compression |
H.265 / H.264 |
|
| Video Bit Rate |
Ultra-HD; HD; Standard. Adaptive bit rate. |
|
| Audio Bit Rate |
Self-Adaptive |
|
| Max. Bitrate |
4 Mbps |
|
| Network |
|
| Wi-Fi Standard |
IEEE802.11a, 802.11b, 802.11g, 802.11n, 802.11ac |
|
| Frequency Range |
2.4G: 2400~2483.5 MHz 5G: 5170~5250 MHz，5735~5835 MHz |
|
| Channel Bandwidth |
Supports 40 MHz |
|
| Security |
64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK |
|
| Transmission Rate |
11b 11Mbps, 11g 54Mbps, 11nHT20 MCS7, 11nHT40 MCS7; 11a 54Mbps, 11nHT20 MCS7, 11nHT40 MCS7 |
|
| Wi-Fi Pairing |
AP pairing |
|
| Protocol |
EZVIZ Cloud Proprietary Protocol |
|
| Interface Protocol |
EZVIZ Cloud Proprietary Protocol |
|
| Wired Network |
RJ45 × 1 (10M / 100M Adaptive Ethernet Port) |
|
| Storage |
|
| Local Storage |
Micro SD card slot (Max. 512G) |
|
| Cloud Storage |
EZVIZ Cloud Storage |
|
| Function |
|
| Smart Alarm |
AI-Powered Human Shape Detection / Pet Detection / Waving-Hand Detection / Voice Activity Detection |
|
| Customized Alert Area |
Supports |
|
| Two-Way Talk |
Supports ( Double Mic ) |
|
| General Function |
Anti-Flicker, Dual-Stream, Heart Beat, Mirror Image, Password Protection, Watermark |
|
| General |
|
| Operating Conditions |
-10°C to 45°C ( 14°F to 113 °F ), humidity 95% or less (non-condensing) |
|
| Power Supply |
DC 5V/2A（Type-C) |
|
| Power Consumption |
Max. 8W |
|
| Product Dimensions |
115.5 × 116 × 160 mm (4.55 × 4.57 × 6.30 inch) |
|
| Packaging Dimensions |
116 × 116 × 164 mm (4.57 × 4.57 × 6.46 inch) |
|
| Weight (With Package) |
487 g (17.18 oz) |
|
| Net Weight |
255 g (8.99 oz) |
|
| In the box |
|
| In the box |
- H6 Camera |
|
| - Base |
|
| - Power Cable |
|
| - Power Adapter |
|
| - Drill Template |
|
| - Screw Kit |
|
| - Quick Start Guide |
|
| - Regulatory Information |
