Description
Specifications
| Brand | HIKVISION |
| Range | CORE |
| Image sensor | 1/3" Progressive Scan CMOS |
| Maximum resolution | 4 Megapixel (2560x1440) |
| Main Stream rate | 20 fps (2560x1440), 25 fps (1920×1080, 1280×720) |
| Extra Stream rate | 25 fps (1280×720, 640×480, 640x360) |
| Compression | H.265+ / H.264+ / H.265 / H.264 |
| Bitrate | 32 Kbps ~ 8 Mbps |
| Lens | 2.8 mm |
| Viewing Angle (FOV) | H: 96°, V: 52°, D: 113° |
| Range performance | 64 m (D), 25 m (O), 12 m (R), 6 m (I) |
| Minimum illumination | Colour: 0.001 Lux @(F1.0, AGC ON) 0 Lux with white light, range 30 m |
| Day/Night | ColorVu: Color image 24 hours |
| Image improvements | WDR (120 dB), BLC, HLC, 3D-DNR, AGC, AWB, ROI, Mirror function, Privacy masking |
| Motion Detection | Motion detection 2.0 with human and vehicle classification applied in motion detection. |
| Internal memory | Does not have |
| Network interface | Ethernet 10/100M BaseT |
| Remote access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200 and Hik-Central |
| Interoperability | ONVIF, ISAPI |
| Power | DC 12 V / 400 mA / 5 W max. / IEEE802.3af PoE |
| Degree of protection | Weatherproof IP67, Vandal-proof IK08 |
| Material | Base: Aluminium alloy Cover: Plastic |
| Temp. operation | -30º C ~ +60º C |
| Dimensions | Ø 121.5 mm x 97.6 mm (H) |
| Base dimensions | Ø base 121.5 mm / Ø entre tornillos 104.7 mm / 3 tornillos |
| Weight | 500 g |
