Description
Specifications
| Specification | Details |
|---|
| Model | DS-1LN6U-W/CCA |
| Product Type | Network Cable |
| Cable Category | Cat6 |
| Cable Type | U/UTP (Unshielded Twisted Pair) |
| Conductor Material | Copper Clad Aluminum (CCA) |
| Conductor Diameter | 23 AWG |
| Number of Conductors | 8 (4 pairs) |
| Insulation Material | HDPE |
| Jacket Material | PE |
| Jacket Color | Black |
| Transmission Bandwidth | Up to 250 MHz |
| Transmission Speed | Up to 1 Gbps |
| Characteristic Impedance | 100 Ω ± 15 |
| Installation Type | Outdoor |
| UV Resistance | Yes |
| Waterproof | Yes |
| Flame Retardant Rating | CM |
| Cable Length per Box | 305 m (1000 ft) |
| Application | Outdoor network cabling, IP cameras, security systems |
| Operating Temperature | -40 °C to 60 °C |
| Storage Temperature | -40 °C to 75 °C |
| Package Type | Pull box |
