Description
Specifications
| Specification | Details |
|---|
| Shell | Metal material |
| Net Weight | 2.96 kg (6.52 lb) |
| Gross Weight | 3.2 kg (7.05 lb) |
| Dimensions (W × H × D) | 440.0 mm × 220.8 mm × 44.0 mm (17.32'' × 8.69'' × 1.73'') |
| Operating Temperature | 0 °C to 45 °C (32 °F to 113 °F) |
| Storage Temperature | -40 °C to 85 °C (-40 °F to 185 °F) |
| Operating Humidity | 5% to 95% (no condensation) |
| Relative Humidity | 5% to 95% (no condensation) |
| Power Supply | 100~240 VAC, 50/60 Hz, Max. 4 A |
| Installation Mode | Rack (equipped with mounting ears) |
| Max. Power Consumption | 250 W |
| Power Consumption in Idle | 30 W |
| Surge Protection | 6 KV |
| Ports | 24 × Gigabit PoE, 1 × Gigabit RJ45, 1 × Gigabit fiber optical |
| MAC Address Table | 8 K |
| Switching Capacity | 56 Gbps |
| Packet Forwarding Rate | 41.66 Mpps |
| Internal Cache | 4.1 Mbits |
| PoE Standard | IEEE 802.3af, IEEE 802.3at |
| PoE Power Pin | 8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-) |
| PoE Port | Ports 1 to 24 |
| Max. Port Power | 30 W |
| PoE Power Budget | 230 W |
| Long Range | Ports 1 to 24: up to 300 m (may vary depending on camera model or cable condition) |
| Port Isolation | Ports 1 to 24: ports in isolation group cannot communicate with each other, but can communicate with ports outside the group |
| PoE Watchdog | Ports 1 to 24: auto detect and restart non-responsive cameras |
| Link Aggregation | Supports static link aggregation, up to 8 aggregation groups, for load balancing, bandwidth expansion, and port protection |
| Loop Prevention | Disabled by default; supports 802.1D STP and 802.1w RSTP |
| VLAN | Supports 802.1Q, configurable VLAN ID 1-4094, Trunk/Access port mode, Max. 32 VLANs |
