Description
Specifications
| Model Version | RE3000 1.0 | |
|---|---|---|
| CPU | CPU Details | 1.3 GHz Dual-Core, ARM Cortex-A53 |
| Memory/Storage | Flash/ROM | 16 MB (128 Mbit) NOR |
| DDR/RAM | 256 MB (2 Gbit) DDR3 | |
| Wireless | 5 GHz Wi-Fi Speed | 2402 Mbps |
| 2.4 GHz Wi-Fi Speed | 574 Mbps | |
| 5 GHz Wi-Fi Streams | 3T3R (3×3 MIMO) | |
| 2.4 GHz Wi-Fi Streams | 2T2R (2×2 MIMO) | |
| Wi-Fi Antennas | 2× Fixed, 1 × Internal | |
| FEM or PA/LNA |
| |
| Range Performance | Max: 150 m (492 ft) Tested in open-space environments with minimal interference. Actual WiFi range may vary depending on layout and wall materials. Refer to the Wall Performance specifications for placement suggestions. | |
| Wall Performance | Two wooden walls with thickness < 10 cm (4'') One concrete wall with thickness < 20 cm (7'') | |
| Interfaces | Gigabit RJ45 Ports | 1 |
| LED |
| |
| Physical Buttons |
| |
| Power Input | AC Plug | |
| Power Input Note | EU, US, UK Plug are Available | |
| Power | Power Methods | AC |
| AC | 100V ~ 240V | |
| Reliability | Environment | Operating Temperature: 0 ℃ ~ 50 ℃ (32 ℉ ~ 122 ℉) Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉) Operating Humidity: 10% ~ 90% non-condensing Storage Humidity: 5% ~ 90% non-condensing |
| Certifications | FCC, CE | |
| Mechanical | Install in a Daisy Chain | Recommend to install less than 3 repeaters in a wireless chain. |
| Installation | Plug-In-Socket | |
| Dimension | 129.6×80×48.6 mm 5.1×3.15×1.91 inches | |
| Product Weight | EU: 279 g (9.84 oz.),UK: 282 g (9.95 oz.),US: 276 g (9.74 oz.) | |
| Package Content |
| |
| Ordering Information | Retail Package Weight | EU: 417 g (14.71 oz.),UK: 405 g (14.29 oz.),US: 422 g (14.89 oz.) |
| Retail Package Dimension | 161×120×96 mm 6.34×4.72×3.78 inches | |
| Units per Carton | 30 | |
| Carton Net Weight | EU: 12.5 kg (27.56 lbs),UK: 12.1 kg (26.68 lbs),US: 12.7 kg (28 lbs) | |
| Carton Gross Weight | EU: 13.3 kg (29.32 lbs),UK: 13.1 kg (28.88 lbs),US: 13.2 kg (29.1 lbs) | |
| Carton Dimension | 50.4×37.7×34.1 cm 19.84×14.84×13.43 inches |
