Specifications
| Brand | HIKVISION |
| Range | CORE |
| Video format | HDTVI / HDCVI / AHD / CVBS / IP |
| Video inputs | 8 Channels BNC (HDTVI / HDCVI / AHD / CVBS) |
| Hybrid configuration | 2CH additional IP: Up to 10 IP channels (6Mpx), substituting all BNC channels Enhanced IP Mode: 4CH additional IPs: Up to 12 IP Channels (4Mpx), replacing all the BNC channels |
| Available bandwidth | 96 Mbps |
| Video outputs | 1 HDMI Full HD and 1 VGA, simultaneous; |
| Display resolution | HDMI: 1920x1080, 1280x1024, 1280x720 VGA: 1920x1080, 1280x1024, 1280x720 |
| Audio inputs | 1 Channel RCA Audio over coaxial |
| Audio outputs | 1 Channel RCA |
| Bidirectional audio | Reusing the audio input |
| Audio compression | G.711u |
| Audio Bit Rate | 64 Kbps |
| Video compression | Analog channels: H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264 IP channels: H.265+ / H.265 / H.264+ / H.264 |
| Recording resolution | With 1080p Lite mode not enabled: 3K Lite / 5Mpx Lite / 4 Mpx Lite / 1080p / 720p / VGA / WD1 / 4CIF / CIF With 1080p Lite mode enabled: 3K Lite / 5Mpx Lite / 4 Mpx Lite / 1080p Lite / 720p Lite / VGA / WD1 / 4CIF / CIF |
| Input resolution | HDTVI: 3K (20 fps), 5 Mpx (20 fps), 4 Mpx (25~30 fps), 1080p (25~30 fps), 720p (25~60 fps) HDCVI: 5 Mpx (20 fps), 4Mpx (25~30 fps), 1080p (25~30 fps), 720p (25~30 fps) AHD: 5 Mpx (20 fps), 4Mpx (25~30 fps), 1080p (25~30 fps), 720p (25~30 fps) CVBS: PAL/NTSC |
| Main Stream coding | With 1080p Lite mode not enabled: For stream 3K: 3K Lite @12fps, 4Mpx Lite/1080p @15fps, 720p/WD1/4CIF/VGA/CIF @20fps [%VAR%] For stream 5Mpx: 5Mpx @12fps, 4Mpx Lite/1080p @15fps, 720p/WD1/4CIF/VGA/CIF @20fps For stream 4Mpx: 4Mpx Lite/1080p @15fps, 720p/WD1/4CIF/VGA/CIF @25fps For stream 1080p: 1080p/720p @15fps, WD1/4CIF/VGA/CIF @25fps With 1080p Lite mode enabled: 3K lite/5Mpx Lite @12fps, 4Mpx Lite @15fps, 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF @25fps [%VAR%] |
| Extra Stream coding | WD1/4CIF (12 fps), CIF (25 fps (P), 30 fps (N)) |
| Video Bit Rate | 32 Kbps at 6 Mbps |
| Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Alarms | Does not have |
| Motion Detection | Motion detection 2.0 with human and vehicle classification applied in motion detection. Available on all analog channels. * Motion detection and AcuSense cannot be enabled at the same time on the same device. |
| Intelligent functions | AcuSense DeepLearning based technology for human and vehicle classification with false alarm reduction applied on: Line Crossing, Area Intrusion, Inbound Region, Outbound Region, Outbound Region Available in 4 analog video channels. * Motion detection and AcuSense cannot be enabled at the same time on the same device. |
| Face detection | Face detection and search |
| Recording method | Manual, programmed, motion detection |
| Backup | USB (Memory, HDD, CD-RW, DVR-RW) / Network |
| Internal memory | 1 SATA HDD 3.5" of up to 10 TB (not included) |
| Communication | 2 x USB 2.0 (rear side) / 1xRJ45 (Ethernet) |
| Remote connections | 64 |
| Remote access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200 and Hik-Central |
| Power | DC 12 V, 1.33 A, ≤ 12 W (no HDD) |
| Operating temperature | -10° ~ +55° C |
| Dimensions / Weight | 45 (H) mm x 200 (W) mm x 200 (D) mm / ≤ 1 Kg (w/o HDD) |
| Colour | White |
