Specifications
| Coil Voltage (Nominal) | 24 VDC |
| Contact Rating (Normally Open - NO) | 40 A at 14 VDC |
| Contact Rating (Normally Closed - NC) | 30 A at 14 VDC |
| Coil Power | Typically 1.8 W |
| Contact Form | 1Z (SPDT - Single Pole Double Throw, 5-pin) |
| Max Switching Voltage | Up to 75 VDC |
| Electrical Life | >100,000 operations |
| Mechanical Life | >10,000,000 operations |
| Operating Temperature | -40°C to +85°C (typical for automotive relays) |
| Dielectric Strength (between contacts & coil) | 750 VAC (for one minute) |
