Specifications
Key Technical Specifications:
- Capacity: 24 SC Simplex adapters (or 24 LC Duplex), designed for 24-core splicing.
- Structure: Usually two layers: upper for patching/distribution, lower for splicing/overlength storage.
- Material: ABS or ABS+PC (polycarbonate), often with IP55-IP65 rating for outdoor (UV resistance) or indoor, wall-mount, or pole-mount installation.
- Dimensions: Roughly
250×215×75mm250 cross 215 cross 75 mm250×215×75mm to
320×240×100mm320 cross 240 cross 100 mm320×240×100mm. - Cable Ports: Multiple cable inlets/outlets for feeder and drop cables (
Φ6∼Φ16mmcap phi 6 tilde cap phi 16 mmΦ6∼Φ16mm). - Weight: Approximately
1.2kg1.2 kg1.2kg to
1.5kg1.5 kg1.5kg. - Optional Features: 1x16 or 1x8 PLC splitter capacity, key lock, and SC/APC or SC/UPC adapters.
- Mechanical Resistance: Lateral pressure-resistance of
500N500 N500N, impact resistance
750N750 N750N.
