Description
Specifications
| Model Version | POE40 1.0 | |
|---|---|---|
| Protocols | 802.3 Protocols |
|
| PoE | Uplink Stream | 1× GbE, 802.3bt/at/af |
| Uplink PIN Assignment | Mode A / Mode B / Four-Pair | |
| Downlink Stream | 4× GbE, 802.3at/af | |
| Downlink Pin Assignment | Mode A | |
| Transimission Distance |
| |
| Interfaces | Power Interfaces | PoE via Ethernet Port |
| Power | Power Methods |
|
| Other Input Requirements | ≥60W is recommended | |
| Max Power Output | 2× 30W or 4× 12.95W | |
| Max Power Output Note | The actual power output depends on input | |
| Max Power Consumption (W) | 2W | |
| Reliability | Power Protection |
|
| EMC | IEC/EN 61000-4-2, Level 3 ESD: Contact: 6kV; Air: 8kV | |
| Grounding Methods | Grounding Point | |
| Environment | Ambient Operating Temperature: 0~45 ℃ (32~113 ℉) Storage Temperature: -40~70 ℃ (-40~158 ℉) Operating Humidity: 10%~95% non-condensing Storage Humidity: 5%~95% non-condensing | |
| Certifications | FCC, CE | |
| Mechanical | Install in a Daisy Chain | Up to 3 extenders in a chain |
| Installation |
| |
| Dimension | 119×85×28 mm 4.69×3.35×1.1 inches | |
| Casing Material | Metal | |
| Product Weight | 254.5 g (8.98 oz.) | |
| Package Content |
| |
| Ordering Information | Retail Package Weight | 327.4 g (11.55 oz.) |
| Carton Net Weight | 14.9 kg (32.85 lbs) | |
| Carton Gross Weight | 15.5 kg (34.17 lbs) |
